13
MIXER PANEL
A
B
C
J
K
D
L M
E
F
G
H
I
N
Power
Button
LCD
Display
Mixer
Knobs
Dynamic LEDs
Power
Inlet
USB
Ports
Limit LED
Mix/Channel Mode Select
Master Volume/Menu Encoder
Back Button
XLR Male
Pass Thru
XLR-1/4”
Combo
6.35mm Hi-Z
Balanced Input
3.5mm Stereo
Un-Balanced Input
