JBL Pulse 4 Service Manual

A1 A2
A3
A4
A5
A6 A7
A8
A9
A10
A11 A12
A13
A14
A15
A16
A17
A18
A19
A20
A21
A22
A23
A24
A25
A27
A26
A28
A29
A30A31
A32
A33
A34
A35
A36
A37
A38
A39
A40
A41
A42
A43
A44
A45
Pos. No. P/N Description UoM Usa
g
e
A
1+A2+A3+A4+
A
5+A6+A45
32200962 TOP CAP ASSY BLK PULSE4 SY 1
A
1+A2+A3+A4+
A
5+A6+A45
32200963 TOP CAP WHT ASSY PULSE4 SY 1
A
10+A41+A43 32200967 INNER BUTTON ASSY PULSE4 SY 1
A
9 31103501 SPEAKER UPPER BRACKET PULSE4 E
A
1
A
E4ESLUP REKAEPS5760021821
A
1
A
14 31601875 VOLUME CONTROL BOARD PULSE4 E
A
1
A
15 31103502 SPEAKER MIDDLE BRACKET PULSE4 E
A
1
A
17 31103504 LED UNDER BRACKET PULSE4 E
A
1
A
20 31300914 INNER BARREL PULSE4 E
A
1
A
21+A22+A27 32200964 OUTER BARREL ASSY BLK PULSE4 SY 1
A
21+A22+A27 32200965 OUTER BARREL ASSY WHT PULSE4 SY 1
A
22 32200858 LOGO ASSY PULSE4 E
A
2
A
23 45901331 BOTTOM SEALING RING PULSE4 E
A
1
A
24 32200849 PR ASSY BLK PULSE4 E
A
1
A
24 32200857 PR ASSY WHT PULSE4 E
A
1
A
26 31200814 BOTTOM COVER BLK PULSE4 E
A
1
A
26 31200820 BOTTOM CAP WHT PULSE4 E
A
1
A
E4ESLUP ABCP BSU3781061382
A
1
A
29+A32+A33 32200966 CONNECTOR ASSY WHT/BLK PULSE4 SY 1
A
31 31200811 IO COVER BLK PULSE4 E
A
1
A
31 31200816 IO COVER WHT PULSE4 E
A
1
A
32 45901345 CHAMBER SEALING RING WHT E
A
1
A
32 45901346 CHAMBER SEALING RING BLK PULSE4 E
A
1
A
34 41700118 LI-ION BATTERY PULSE4 E
A
1
A
36 31601709
A
MPLIFIER PCBA PULSE4 E
A
1
A
37+A19 32100619 LED PCBA ASSY PULSE4 E
A
1
A
38 31103503 LED UPPER BRACKET PULSE4 E
A
1
A
39 31601876 RGB LIGHT BOARD PULSE4 E
A
1
A
1YS4ESLUP DRAOB TB9781061304
MECHANICAL EXPLODED VIEW

JBL Pulse 4 Specifications

General

Wi-Fi	-
Bluetooth	Yes
Cord length	1.2 m
3.5 mm connector	No
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP
USB connector type	USB Type-C
Connectivity technology	Wireless
Product color	Black
Product design	Cylinder
Volume control	Buttons
Housing material	Plastic
Protection features	Waterproof
International Protection (IP) code	IPX7
Frequency range	70 - 20000 Hz
RMS rated power	20 W
Signal-to-Noise Ratio (SNR)	80 dB
Battery type	Built-in battery
Battery capacity	7260 mAh
Power source type	Battery, USB
Battery life (max)	12 h
Recommended usage	Universal
Mobile operating systems supported	Android, iOS
Cables included	USB Type-A to USB Type-C
Woofer diameter	50 mm
Number of speakers	1
Woofer diameter (imperial)	2.25 \
Package depth	246 mm
Package width	113 mm
Package height	140 mm
Package weight	1770 g
Pallet length	1200 mm
Quantity per pallet	276 pc(s)
Master (outer) case width	154 mm
Quantity per pallet layer	46 pc(s)
Master (outer) case height	272 mm
Master (outer) case length	245 mm
Master (outer) case volume	0.01 cm³
Master (outer) case weight	3940 g
Number of layers per pallet	6 pc(s)
Number of cartons per pallet	138 pc(s)
Master (outer) case GTIN (EAN/UPC)	6925281958311
Export Control Classification Number (ECCN)	China
Pallet net weight	543720 g

Weight and Dimensions

Depth	96 mm
Width	207 mm
Weight	1260 g
