JBL PX300.4 Service Manual

TRS-00-00087 TRANSISTOR SMALL SIGNAL PNP KTA1023Y
5
Q16,133,233,333,433
TRS-00-00088 TRANSISTOR SMALL SIGNAL NPN KTC1027Y
4
Q143,243,343,443
TRS-00-00090 TRANSISTOR SMALL SIGNAL PNP KTA1266GR
6
Q1,2,5,6,12.13
TRS-00-00091 TRANSISTOR SMALL SIGNAL PNP KTA1268GR
9
Q4,141,142,241,242,341,342,441,442
TRS-00-00110 TRANSISTOR SMALL SIGNAL NPN KTC3198GR
5
Q11,14,15,152,252
TRS-00-00109 TRANSISTOR SMALL SIGNAL NPN KTC3198BL
1
Q3
TRS-00-00111 TRANSISTOR SMALL SIGNAL NPN KTC3200GR
12
Q131,132,151,231,232,251,331,332,351,431
Q432,451
TRS-00-00073 F.E.T N-CH JFET KTK30AGR
5
Q61,101,201,301,401
DIO-00-00006 DIODE SWITCHING SIGNAL DIODE 1SS133
15
D2,3,4,9,10,61,62,151,251,351
D451,801,802,803,804
DIO-00-00003 DIODE RECTIFIER 1N4004
1
D1
DIO-00-00020 DIODE ZENNER DIODE 1W 15V 1N4744
4
D191,291,391,491
DIO-00-00108 DIODE FAST RECOVERY FR154
8
D51,52,53,54,55,56,57,58
RES-00-00523 RESISTOR METAL FILM 1/5WF 4.7KOHM
1
R27
RES-00-00545 RESISTOR METAL FILM 1/5WF 5.6K OHM
4
R127,227,327,427
RES-00-00589 RESISTOR METAL FILM 1/5WF 9.4K OHM
2
R112,312
RES-00-00399 RESISTOR METAL FILM 1/5WF 10.5K OHM
1
R26
RES-00-00425 RESISTOR METAL FILM 1/5WF 15K OHM
2
R212,412
RES-00-00421 RESISTOR METAL FILM 1/5WF 15.2K OHM
4
R111.211.311.411
RES-00-00467 RESISTOR METAL FILM 1/5WF 22K OHM
4
R131,231,331,431
RES-00-00537 RESISTOR METAL FILM 1/5WF 47K OHM
10
R102,103,113,202,203,302,303,313,402,403
RES-00-00556 RESISTOR METAL FILM 1/5WF 56K OHM
8
R107,108,207,208,307,308,407,408
RES-00-00591 RESISTOR METAL FILM 1/5WF 91K OHM
6
R101,201,301,401,213,413
RES-00-00610 RESISTOR CARBON FILM 1/5WJ 10 OHM
1
R5
RES-00-00660 RESISTOR CARBON FILM 1/5WJ 22 OHM
16
R135,136,145,146,235,236,245,246.335,336
R345,346,435,436,445,446
RES-00-00716 RESISTOR CARBON FILM 1/5WJ 47 OHM
16
R22,23,24,25,36,37,38,39,137,147
R237,247,337,347,437,447
RES-00-00622 RESISTOR CARBON FILM 1/5WJ 150 OHM
4
R151,251,351,451
RES-00-00662 RESISTOR CARBON FILM 1/5WJ 240 OHM
2
R381,481
RES-00-00741 RESISTOR CARBON FILM 1/5WJ 680 OHM
1
R6
RES-00-00756 RESISTOR CARBON FILM 1/5WJ 820 OHM
4
R110,210,310,410
RES-00-00633 RESISTOR CARBON FILM 1/5WJ 1K OHM
20
R7,20,21,34,35,42,109,134,144,209
R234,244,309,334,344,409,434,444,809,812
RES-00-00595 RESISTOR CARBON FILM 1/5WJ 1.2K OHM
6
R28,43,172,272,372,472
RES-00-00598 RESISTOR CARBON FILM 1/5WJ 1.5K OHM
4
R154,254,354,454
RES-00-00602 RESISTOR CARBON FILM 1/5WJ 1.8K OHM
2
R383,483
RES-00-00644 RESISTOR CARBON FILM 1/5WJ 2.7K OHM
4
R148,248,348,448
RES-00-00676 RESISTOR CARBON FILM 1/5WJ 3.9K OHM
5
R2,138,238,338,438
RES-00-00702 RESISTOR CARBON FILM 1/5WJ 4.7K OHM
3
R1,13,14
RES-00-00720 RESISTOR CARBON FILM 1/5WJ 5.6K OHM
16
R116,119,122,125,216,219,222,225,316,319
R322,325,416,419,422,425
RES-00-00734 RESISTOR CARBON FILM 1/5WJ 6.8K OHM
16
R118,124,133,143,218,224,233,243,318,324
R333,343,418,424,433,443
RES-00-00751 RESISTOR CARBON FILM 1/5WJ 8.2K OHM
1
R12
RES-00-00608 RESISTOR CARBON FILM 1/5WJ 10K OHM
38
R3,4,29,62,104,114,115,120,121.126
R128,130,204,214,215,220,221,226.228.230
R304,314,315,320,321,326,328,330.404.414
R415,420,421,426,428,430,805,810
RES-00-00623 RESISTOR CARBON FILM 1/5WJ 15K OHM
6
R10,33,155,255,355,455
RES-00-00630 RESISTOR CARBON FILM 1/5WJ 18K OHM
4
R171,271,371,471
RES-00-00658 RESISTOR CARBON FILM 1/5WJ 22K OHM
10
R8,16,117.123,217,223,317,323,417,423
RES-00-00733 RESISTOR CARBON FILM 1/5WJ 6.2K OHM
1
R807
RES-00-00663 RESISTOR CARBON FILM 1/5WJ 24K OHM
2
R105.205
RES-00-00666 RESISTOR CARBON FILM 1/5WJ 27K OHM
3
R17,806,811
RES-00-00687 RESISTOR CARBON FILM 1/5WJ 33K OHM
2
R9,808
RES-00-00697 RESISTOR CARBON FILM 1/5WJ 39K OHM
2
R382,482
RES-00-00724 RESISTOR CARBON FILM 1/5WJ 51K OHM
1
R31
RES-00-00730 RESISTOR CARBON FILM 1/5WJ 56K OHM
6
R44.45,156,256,356,456
RES-00-00748 RESISTOR CARBON FILM 1/5WJ 75K OHM
4
R801,802,803,804
RES-00-00604 RESISTOR CARBON FILM 1/5WJ 100K OHM
3
R63,106,206
RES-00-00647 RESISTOR CARBON FILM 1/5WJ 200K OHM
2
R380,480
RES-00-00654 RESISTOR CARBON FILM 1/5WJ 220K OHM
1
R61
RES-00-00706 RESISTOR CARBON FILM 1/5WJ 430K OHM
1
R11
RES-00-00278 RESISTOR CARBON FILM 1/4WJ 10 OHM
1
R15
RES-00-00312 RESISTOR CARBON FILM 1/4WJ 220 OHM
2
R18,19
RES-00-00053 RESISTOR CARBON FILM 1/2WJ 4.7 OHM
4
R161,261,361,461
