SRX835P SPECIFICATIONS
Bottom View Front View Left View Rear View
System Specification
System Type: Self powered 15”, three-way, bass-reflex
Maximum SPL Output: 137dB
Frequency Range (-10dB): 33Hz - 21kHz
Frequency Response (-3dB): 41Hz - 20kHz
Amplification
System Power Rating: 2000W Peak, 1500W Continuous
Input Impedance: 40k balanced, 20k unbalanced
Line Input Gain: 21 dB
Consumer Input Gain: 33 dB
Mic Input Gain: 45 dB
Maximum Input Level:
s
Line: 20dBu
s
Consumer: 8dBu
s
Mic: -4dBu
Connectors: Neutrik 1/4 - XLR input; Neutrik XLR Output
LED Indicators: Power LED (Green), Network Link (Green), Network Data (Yellow)
Cooling: On-Demand variable speed fan
AC Power Input: 100 - 240V~ 50/60Hz
AC Power Consumption (120V~): 2.2A (1/8th Power), 5.6A (1/3rd Power)
Speaker Specification
LF Driver: 2275F
MF Driver: 2107H
HF Driver: 2432H
Coverage Pattern: 60 x 40
Crossover Frequency: 330Hz & 2.4kHz
Enclosure
Material: 18mm plywood
Suspension/Mounting: Single 36mm pole socket, 12 x M10 Suspension points
Handles: 2
Finish: Obsidian Duraflex™ finish
Grille: Powder coated, Obsidian, 14-gauge perforated steel with acoustically transparent black cloth backing
Dimensions (L x W x H): 18.74” x 21.4” x 38.74” (476mm x 544mm x 984mm)
Weight: 85.0 lbs (38.6kg)
Shipping Weight: 97.0 lbs (44.0kg)
*For exact specifications including precise placement of suspension points and frequency response curves for JBL presets, find spec sheets at
http://www.jblpro.com/www/products/portable-market/srx800-series
984 mm
38.74 in
476 mm
18.74 in
544 mm
21.40 in
