JBL SUB 140P/230 User Manual

118-08050000F-E SMD resistor 0 0805 1% RoHS 3 C1,R1,R8
118-08051000F-E SMD resistor 0805 1/10W 100 ±1% LF 1 R7
118-08051002F-E SMD resistor 10K 0805 1/10W ±1% LF
(
RoHS
)
3 R2,R6,R10
118-080510R0F-E SMD resistor 0805 10ohm 1%
(
RoHS
)
2 R3,R4
118-08051542F-E SMD resistor 0805 1/16W 15K4 ±1%LF RoHS 1 R11
118-08052001F-E SMD resistor 0.1W 1% 2K
(
RoHS
)
1 R12
118-08052491F-E SMD resistor 2.49K 0805 1/10W 1%
(
RoHS
)
1 R5
118-08054302J-E SMD resistor 0805 43K 5%
(
ROHS
)
1 R15
141-B0102K50-E SMD ca
p
acitor 0.001uF NPO 080550V 10% 1 C4
141-B7103K50-E SMD ca
p
acitor 0.01U 50V X7R 0805
(
RoHS
)
2 C6,C8
141-B7104K50-E
capacitor CAP SMD 0805 X7R0.1uF ±10% 50V
LF/RoHS
2 C2,C3
141-B7105K25-E SMD ca
p
acitor 1U 25V 0805 X7R10%
(
RoHS
)
1 C5
141-B7474K50-E ca
p
acitor 0.47U 50V 10% X7R0805 RoHS 1 C10
190-16SG3525AP-E IC SG3525AP SOP ST3*16
p
in
(
RoHS
)
1 U1
197-0SL4148WP-E SMD diobe LL4148WP 1206SHAWELL
(
RoHS
)
1 D1
175-9B08H02-E connector 8PIN PITCH=2.0mm 90
(
RoHS
)
1 CN1
109-1SCK0480-E resistor NTC SCK048 1 TH1
109-2VR104710-E absorber TVR10471
(
RoHS
)
TVR10471KSY 1 ZNR1
110-10510J5V-E resistor 51 1W ±5% 1 R23
110-12104J5V-E resistor 100K 1/2W 5% 1 R3
122-116R0M010-E inductor CR310-6ROMS RoHS 1 L1
122-14124M05001-E inductor :0.5mm EMI
(
RoHS
)
2 LF1,LF2
122-14152K036-E filter UU-98 0703 1 CT1
122-14171K0700-E inductor FERRITE CORE 170uH 1 L2
130-3F101MD00-E Y1 ca
p
acitor 100P Y5U20% 250V 2 CY1,CY2
130-3F102MB50-E ca
p
acitor Y1 1NF 20% 1 CY4
130-3F222MD00-E ca
p
acitor 2200PF 400V ±20% Y1
(
RoHS
)
1 CY3
132-105KB54-E ca
p
acitor 1uF 250V±10% LS:15mm 1 C28
132-224KB54-E
capacitor 0.22uF 250V AC+/-10%W18*H13.5*T5.0
P=15mm
1 CX2
132-334KB74-E ca
p
acitor 0.33uF 275V +/-10% LS=15mm 1 CX1
135-C127M200-E ca
p
acitor 120uF 200V 105 16X25 2 C1,C4
150-SEE1602-E transformer EE-16 RoHS 1 T1
150-SERL2803-E transformer ERL28
(
RoHS
)
1 T2
150-STF16021-E
transformer TF-1602-1 EEL-16DT1
0804/0805/0703
(
RoHS
)
1 DT1
162-10059001-E wire 50mm WHITE UL1007 AWG266:6
(
RoHS
)
1 JP12
175-1C04V01-E connector 4PIN PITCH=2.5mm
(
RoHS
)
1 CN2
175-1D02V01-E connector 2PIN PITCH=3.96mm
(
RoHS
)
1 CN4
175-1D03V02-E connector 3PIN JWT A3963
(
RoHS
)
1 CN1
190-99B0365JG-E INFINEON IC ICE3B0365JG
(
RoHS
)
PG-DIP-8-6 1 U1
190-99PC817C-E IC PC817C
(
COSMO
)
(
RoHS
)
1 U2
192-993A14N50C-E Transistor IPS FTA14N50C TO-220F500V14A 2 Q6,Q7
193-0S018012-E Insulation chi
p
OTHER SILCON 18mm*12mm 1
197-000GBU406-E rectifier 4A 600V GBU406 RoHS 1 BR1
197-000UF4007-E diode UF4007
(
RoHS
)
1 D2
197-00MUR1220CT-
E
diode MUR1220CT HI-SEMICON200V 12A
TO220
(
RoHS
)
1 D8
197-03SR160-E diode MIC SR160 DO-41 60V 1ATAP RoHS 2 D1,D9
197-30SF16-E rectifier SF16
(
RoHS
)
1 D6
197-60MBR1200-E diode Pan
j
it MBR1200 DO-41200V1A RoHS 1 D4
323-AL-05205-0LAE heat sink 76*28*8mm
(
RoHS
)
1
323-AL-05206-0LAE heat sink 52*28*8mm 1
351-AM03008A078-E M3*8 "Machine screw cross with 7
361-NYL-00054-0LAE
Insulation
p
ad
(
SW06002
)
(
RoHS
)
1
PCB ASS'Y SUB140/230 POWER-SOURCE EUP RoHS
JBL
SUB
140P/230
Service
Manual
Page 11 of
28
