Rated Power Output 150W per channel into 8 ohms, all channels driven
THD < 0.03% 20Hz - 20kHz
Input Impedance 28k ohms
Sensitivity 1V in = 100 watts out (THX Standard)
1.25V in = 150 watts out
Frequency Response ( at 1 W ) 20Hz - 20kHz + 0, – 0.25dB
S/N Ratio ( A-weighted at rated power ) ≥ 100dB
Damping Factor ( 8 ohms ) ≥ 400
Power Bandwidth 5Hz - 100kHz + 0, – 3dB
IM Distortion ≤ 0.03%
Unit Size 7” H x 19” W x 19
¹⁄₂
” D — 178 mm x 484 mm x 495 mm
Unit Weight 97 Ibs — 44 kg
Shipping Weight 111 Ibs — 50 kg
All features and specifications are subject to change without notice.
Lucasfilm Ltd. and THX are trademarks or registered trademarks of Lucasfilm Ltd.
19
7.0
SPECIFICATIONS
7.0
SPECIFICATIONS
