Rated Power Output 200W in stereo mode into 8 ohms -- 800W in bridged mode into 8 ohms
THD < 0.03% 20Hz - 20kHz
Input Impedance 28k ohms
Sensitivity 1V in = 100 watts out (THX Standard)
1.4V in = 200 watts out
Frequency Response ( at 1 W ) 20Hz - 20kHz +0, -0.25dB
S/N Ratio ( A-weighted at rated power ) ≥ 100dB
Damping Factor ( 8 ohms ) ≥ 400
Power Bandwidth 5Hz - 100kHz +0, –3db
IM Distortion ≤ 0.03%
Unit Size 7” H x 19” W x 17
¹⁄₂
” D — 178 mm x 484 mm x 444 mm
Unit Weight 70 Ibs — 32 Kg
Shipping Weight 82 Ibs — 37 Kg
All features and specifications are subject to change without notice.
"LUCASFILM THX AUDIO" and "HOME THX CINEMA" are trademarks of Lucasfilm Ltd.
22
7.0
SPECIFICATIONS
