jcb 1 86C-1 TAB User Manual

65R-1, 67C-1, 85Z-1, 86C-1, 90Z-1, 100C-1 21
Fluids and Lubricants 65R-1 / 67C-1
Item Capacity Fluid / Lubricant
JCB Part
Number
Container
Size
Fuel Tank 83L Diesel Oil
- -
Engine (Oil) 9.1L
Above -10°C (14°F):
JCB Ultra performance 10W30
4001 / 3005 20L
JCB Ultra performance 5W30
4001 / 3105 20L
Engine Coolant 11.9 L
JCB Antifreeze HP/Coolant/
Water
4006 / 1120 20L
Track Gearbox (each) 0.8L
JCB Engine Oil HP SAE 30
(Not Multigrade)
4001 / 0305 20L
Track Idler Wheels 0.8L JCB HD90 Gear Oil
4000 / 0305 20L
Track Rollers (top) 0.3L JCB HD90 Gear Oil
4000 / 0305 20L
Track Rollers (bottom) 0.8L JCB HD90 Gear Oil
4000 / 0305 20L
Hydraulic System
System 92.5
Tank 57.2
-20°C (-4.0°F) to 46°C (114.7°F):
JCB Hydraulic Fluid OP46
4002 / 2005 20L
Slew Ring Bearings As required JCB HP Grease
4003 / 2017 0.4kg
Slew Ring Gear Teeth As required JCB Special Slew Pinion Grease
4003 / 1619 0.4kg
All Other Grease As required JCB MPL-EP Grease
4003 / 1501 0.4kg
