jcb 205 User Manual

About the Product
Description
9 9811/9500-4 9
Main Component Locations
The illustration shows a typical machine model. Your machine may look different from the one shown.
Figure 5.
4
3
6
8
7
1
2
5
9
1 ROPS/FOPS cab 2 Fuel tank filler point
3 Lift arm/boom 4 Front working lights
5 Quickhitch 6 Rubber tracks
7 Engine top cover 8 Wheels/tyres
9 Exhaust
