About the Product
Description
9
9831/3100-2
9
Main Component Locations
Figure 4.
E
F
G
H
J
A
B
C
D
A
Loader arm
B
Canopy
C
Hydraulic oil tank
D
Battery Compartment
E
Boom
F
Fuel tank
G
Stabilisers
H
Kingpost
J
Dipper
Y
our machine might have a cab instead of canopy which is optional.
