About the Product
Product and Component Identification
11 9831/3950-1 11
Figure 10. Front axle
A Data plate - front axle
Figure 11. Rear axle
A Data plate - rear axle
Gearbox
The gearbox has a serial number stamped on a data plate as shown.
Figure 12.
A Data plate
Operator Protective Structure
WARNING You could be killed or seriously injured if you operate a machine with a damaged or missing
ROPS/FOPS. If the ROPS/FOPS has been in an accident, do not use the machine until the structure has
been renewed. Modifications and repairs that are not approved by the manufacturer may be dangerous and
will invalidate the ROPS/FOPS certification.
WARNING Machines with a ROPS/FOPS are equipped with a seat belt. The ROPS/FOPS is designed to
give you protection in an accident. If you do not wear the seat belt you could be thrown off the machine and
crushed. You must wear a seat belt when using the machine. Fasten the seat belt before starting the engine.
