jcb 427 User Manual

01 - Machine
09 - Description
12 - Main Component Locations
01 - 21 9813/6100-4 01 - 21
12 - Main Component Locations
Introduction
Figure 5.
A
D
B
C
G
H
J
K
L
E
F
A ROPS (Roll-Over Protective Structure)/FOPS
(Falling Object Protective Structure) cab
B Shovel ram
C Loader arms D Shovel
E Engine/Engine cover F Wheels/tyres
G Chassis H Steps
J Fenders K Battery box
L Articulation rams
