Section B - Body and Framework
Fig 10. 993/68100 Slide Hammer Kit
1 993/68101 Slide Hammer 7 993/68107 Bar - M20 x M20 X 800 mm
2 993/68102 End Stops 8 993/68108 Adaptor - M20 x 7/8" UNF
3 993/68103 Adaptor - M20 x 5/8" UNF 9 993/68109 Adaptor - M20 x M12
4 993/68104 Adaptor - M20 x 1" UNF 10 993/68110 Adaptor - M20 x 5/8" UNF (Shoulder)
5 993/68105 Adaptor - M20 x M20 11 993/68111 Adaptor - M20 x 1/2" UNF
6 993/68106 Adaptor - M20 x M24
Fig 11. Rivet Nut Tool
1 826/01099 M6 x 16 mm Rivet Nut
826/01101 M6 x 19 mm Rivet Nut
826/01102 M8 x 18 mm Rivet Nut
826/01103 M8 x 21 mm Rivet Nut
826/01104 M10 x 23 mm Rivet Nut
826/01105A M10 x 26 mm Rivet Nut
2 - Installation Tool available from: Bollhoff
Fastenings Ltd (www.bollhof.com)
