jcb 516-40 TIER 3 User Manual

Introduction
Safety Check List
12 12
9821-9750-2
!MWARNING
Should the machine start to roll over, you can be
crushed if you try to leave the cab. If the machine
starts to roll over, do not try and jump from the cab.
Stay in the cab, with your seat belt fastened.
INT-2-1-12
Maintenance Safety
!MWARNING
Communications
Bad communications can cause accidents. If two or
more people are working on the machine, make sure
each is aware of what the others are doing. Before
starting the engine make sure the others are clear of
the danger areas; examples of danger areas are: the
rotating blades and belt on the engine, the
attachments and linkages, and anywhere beneath or
behind the machine. People can be killed or injured if
these precautions are not taken.
INT-3-1-5
!MWARNING
Repairs
If your machine does not function correctly in any way,
get it repaired straight away. Neglect of necessary
repairs could result in an accident or affect your
health. Do not try to do repairs or any other type of
maintenance work you do not understand. To avoid
injury and/or damage get the work done by a specialist
engineer.
GEN-1-5_2
!MWARNING
Metal Splinters
You can be injured by flying metal splinters when
driving metal pins in or out. Use a soft faced hammer
or copper pin to remove and fit metal pins. Always
wear safety glasses.
INT-3-1-3_2
!MWARNING
Electrical Circuits
Understand the electrical circuit before connecting or
disconnecting an electrical component. A wrong
connection can cause injury and/or damage.
INT-3-1-4
