jcb 526-56 - Axle(s)

About the Product
Product and Component Identification
15 9831/0100-6 15
Axle(s)
For: 550-80 [T4F], 550U80 [T4F], 560-80 [T4F], 560U80 [T4F] ............................................... Page 15
Otherwise .................................................................................................................................. Page 15
(For: 550-80 [T4F], 550U80 [T4F], 560-80 [T4F], 560U80 [T4F])
The axles have a serial number stamped on a data plate label as shown.
To view the front axle data plate remove the cover. The plate will be visible through hole.
Figure 7. Front axle
A
B
A Cover B Data plate - front axle
Figure 8. Rear axle
C
C Data plate - rear axle
(Otherwise)
The axles have a serial number stamped on a data plate as shown.
