STRING REPLACEMENT
See Figure 8.
Use 2.4 or 2.8 mm diameter monofilament line. For best performance, use the original
manufacturer's replacement line.
1. Stop the engine and disconnect the spark plug lead.
2. Pull and remove the old line from the holes located on top of the string head.
3. Use 2 pieces of the provided pre-cut trimmer lines or cut 2 pieces of trimmer lines,
28 cm in length.
4. Insert the line into the slots located at both sides of the string head. The line should
be pushed in until about 2.5 cm is left protruding from the holes of the string head.
Note: The string head has no string line extending function. Do not tap the string
head on the ground.
BLADE PROTECTOR
See Figure 9.
Always place the blade protector on the blade when the unit is not in use. The blade
protector has clips around the edges to snap over the blade and keep it in place.
Wear gloves and be cautious when handling the blade.
Note: Always remove the blade protector before using the unit. If not removed,
the blade protector could become a thrown object as the blade begins to turn.
CLEANING THE EXHAUST PORT AND SILENCER
Depending on the type of fuel used, the type and amount of oil used, and/or your
operating conditions, the exhaust port and silencer may become blocked with
carbon deposits.
If you notice power loss with your petrol-powered tool, contact a qualified service
technician to remove these deposits and restore performance.
SPARK ARRESTOR CLEANING OR REPLACEMENT
The spark arrestor must be cleaned or replaced every 25 hours or yearly to ensure
proper performance of the product.
Spark arrestors may be in different locations depending on the model purchased.
Please contact your nearest service dealer for the spark arrestor location of your
model.
