jcb S4550E User Manual

Technical Data
Static Dimensions
85 9831/3200-3 85
Description Dimension
Overall length (stowed) 2.39m
Overall width (stowed) 0.81m
Overall height (stowed, guardrail folded) 1.83m (6' 0")
Overall height (stowed, guardrail unfolded) 2.22m (7' 3")
(For: S2046E)
Table 17.
Description Dimension
Maximum platform height 6.3m (20' 8")
Maximum working height 8.3m (27' 2")
Platform size (L x W x H) 2.25m x 1.15m x 1.1m
Ground clearance 0.1m
Wheelbase 1.85m
Extension outreach 0.9m
Overall length (stowed) 2.39m
Overall width (stowed) 1.15m
Overall height (stowed, guardrail folded) 1.83m (6' 0")
Overall height (stowed, guardrail unfolded) 2.22m (7' 3")
(For: S2632E)
Table 18.
Description Dimension
Maximum platform height 8.1m (26' 6")
Maximum working height 10.1m (33' 1")
Platform size (L x W x H) 2.25m x 0.81m x 1.1m
Ground clearance 0.1m
Wheelbase 1.85m
Extension outreach 0.9m
Overall length (stowed) 2.39m
Overall width (stowed) 0.81m
Overall height (stowed, guardrail folded) 1.96m (6' 5")
Overall height (stowed, guardrail unfolded) 2.35m (7' 8")
(For: S2646E)
Table 19.
Description Dimension
Maximum platform height 8.1m (26' 6")
Maximum working height 10.1m (33' 1")
Platform size (L x W x H) 2.25m x 1.15m x 1.1m
Ground clearance 0.1m
Wheelbase 1.85m
Extension outreach 0.9m
Overall length (stowed) 2.39m
Overall width (stowed) 1.15m
Overall height (stowed, guardrail folded) 1.96m (6' 5")
Overall height (stowed, guardrail unfolded) 2.35m (7' 8")
