03 - Attachments, Couplings and Load Handling
09 - Lift Arm Quickhitch
30 - Carriage
03 - 11
9813/2350-5
03 - 11
30 - Carriage
Lubricate
1.
Remove any attachments
before you grease
the
locking pins.
2.
Use
the
relevant
grease
gun
to
grease
the
points
shown. Refer to (PIL 75-06).
Figure 9.
1
Grease point 1
2
Grease point 2
42
44
