© Jeff Rowland design gRoup 2007. all Rights ReseRved.
13
Output Power, Continuous RMS 500 watts @ 8 ohms, 1000 watts @ 4 ohms
Frequency Response 5 Hz – 45 kHz, -3 dB @ 8 ohms
Peak Output Current 40 amps
Dynamic Range 120 dBa
Load Impedance Range 2 ohms – 16 ohms
Input Impedance 40k ohms
THD + Noise, 0.1 watts – 500 watts, 4 ohms < 0.1%, Typically .01% @ 1 kHz
CCIF Intermodulation Distortion, 19/20 kHz < .002%
Damping Factor @ 1 kHz > 1000
Overall Gain (Balanced or Unbalanced) Selectable Internal Jumper, 26 or 32 dB
Common Mode Rejection Ratio > 90 dB, 20 Hz – 20 kHz
Absolute Phase Non-inverting, Pin 2 Positive
Inputs
1 Balanced (XLR)
(Unbalanced operation requires an optional XLR to RCA adapter)
Outputs 1 CE-Approved Speaker Wire Clamp
Power Consumption Idle – 15 watts, Maximum – 1300 watts
Amplifier Weight
17 lbs. / 7.8 kg
Overall Amplifier Dimensions (H) x (W) x (D)
3.3” x 8.4” x 14.6”
85mm x 213mm x 372mm
OWNER’S MANUAL MODEL 501 MONO AMPLIFIER
