Model 8T/Ti Performance Specifications
Output Power
Continuous RMS watts
@ 8 ohms 250 watts
@ 4 ohms 400 watts
Power Bandwidth 0.1 Hz to 160 kHz, -3 dB
Slew Rate 30 volts per microsecond
THD and Noise Less than 0.1% at rated power
Damping Factor Greater than 100, 20 Hz to 20 kHz, 8 ohms
Output Current 50 amps continuous, 100 amps peak
Overall Gain
& Sensitivity
User selectable on rear panel
(1 watt, 8 ohms) 26 dB or 32 dB; 141 mV or 71 mV
Input Impedance User selectable on rear panel
Unbalanced 36k or 600 ohms
Balanced 36k or 600 ohms
Common Mode
Rejection Ratio
Greater than 60 dB, 20 Hz to 20 kHz
Absolute Phase User selectable on rear panel
Unbalanced input Normal
Balanced input Normal or Phase-inverted
Input Mute User selectable on rear panel
Power Consumption 100 watts standby; 300 watts operating, idle;
1200 watts maximum
Inputs User selectable on rear panel
Unbalanced 2 RCA connector
Balanced 2 XLR connector
Outputs 2 pair binding posts per channel
Dimensions 17.5 in. (W) x 22 in. (D) x 11.4 in. (H)
44.5 cm (W) x 56 cm (D) x 28.5 cm (H)
Shipping Dimensions 18.0 in. (W) x 24.0 in. (D) x 28.0 in. (H)
45.7 cm (W) x 61 cm (D) x 71.1 cm (H)
Weight 124 lbs. (56 kg)
Shipping Weight 164 lbs. (75 kg)
Because Jeff Rowland Design Group is constantly analyzing new
design improvements, we reserve the right to change or modify product
specifications without notice or obligation.
Operation / Specifications
