john deer LA115 User Manual

Operating Controls - 11
OPERATING CONTROLS
Operating Controls
Operator Station Controls (LA105)
MX27230
ABrake/Clutch Pedal
B Park Brake Lock Lever
C Throttle/Choke Lever
D Reverse Implement Option (RIO) Switch
E Service Reminder/Hour Meter
FKey Switch
G Attachment Engagement Lever
H Deflector Shield
I Transmission Shift Lever
J Fuel Level Window
K Attachment Lift Lever
A
G
F
J
C
D
B
K
I
H
E

john deer LA115 Specifications

General

Engine Power	19 hp
Transmission	Hydrostatic
Cylinders	1
Drive	2WD
Blades	2
Fuel Type	Gasoline
Cutting Width	42 in
Wheelbase	48.9 in
Turning Radius	18 in. (45.7 cm)
