T5000 LCD Digital Fan Coil Thermostat-Installation Instructions
T5000 液晶数字式风机盘管温控器-安装说明
Time-On and Time-Off Operation
Hold down the "
M
" button for 3 seconds will enter the Timer On-Off setting. When the "
"、"
ON
" and ''
hh
'' of ''
hh mm
'' appear, press "▲" and "
▼
" keys to set the time duration .
To confirm setting, press M/ button once, press other keys to cancel the setting.
Press "
M
" button again, "
"、"
OFF
" and ''
mm
'' of ''
hh mm
'' appear, press "▲" and
"
▼
" keys to set the time duration. Set time duration to "
--
", to cancel the setting. After
one cycle for Time-on and Time-off the setting will be automatically canceled.
Lock function
Lock function: The thermostat will be locked automatically after 30 seconds under
the lock function. Hold down the fan key 5 seconds to unlock.
Unoccupied energy-saving mode
（T5200-TB-9JS0）
Unoccupied energy-saving mode (by entrance card): While entrance card is pulled
out, the temperature automatically set to 26℃, fan is on LO-speed if the thermostat
is in cool mode; the temperature set to 18℃, fan is on LO-speed if in heat mode.
Low Temperature protection setting
On power Off status and when room temperature is lower than 5℃, heat function
will be automatically switched on, "
" appears, the fan is set to HI-speed and
the valve (heat valve for T5200-TF-9JS0, T5200-TF-9JR0) is opened. When the
room temperature reaches 7℃, the setting will be automatically canceled.
On power Off status, press "
M
" and keep 5 seconds, display "
OF
" or "
On
",
press "▲"、"
▼
" to adjust the parameter. "
OF
" means cancelling low temperature
protection, "
On
" means the protection function is on. Factory setting is "
OF
".
Remote Temperature sensor
（T5200-TB-9JR0, T5200-TF-9JR0)
When remote sensor is connected, the built-in sensor will be disable.
定时开关机设置
定时开关机设置：开机状态下，按住“
M
”键并保持3秒，直至“
”、
“
ON
”和“
hh mm
”的“
hh
”符号同时闪烁，此时按“▲”或“
▼
”键调
整延时多少小时定时开机。再按“
M
”键，“
”、“
OFF
”和“
hh mm
”的
“
mm
”符号同时闪烁，此时按“▲”或“
▼
”键调整延时多少小时定时关
机。取消定时开关机设置：只要把定时开关机的时间调整为“
--
”即可；或
者当定时开关机功能运行过一次后，会自动取消定时开关机。
锁按键功能
锁按键功能：如果温控器开启了锁按键功能，在没有人使用的情况下30秒后
会自动把按键锁上。按风速按键5秒即可解锁。
门卡节能模式
（T5200-TB-9JS0）
可通过门卡进入节能模式。当门卡拔出后，如果温控器处于制冷模式时，温
度自动设置为26℃，风机低速运行；如果温控器处于制热模式时，温度自动
设置为 18℃，风机低速运行；
低温保护功能的设置
温控器处于关机状态，当室内温度低于5℃时，温控器自动开启制热并显示
“
”符号，风机自动高速运行并开启电动阀（T5200-TF-9JS0，T5200-
TF-9JR0开启热水阀）；当室内温度升高到7℃时，温控器自动关闭输出。
关机状态下，按住“
M
”键并保持5秒，显示“
OF
”或“
On
”，按“▲”、
“
▼
”键调整此项参数。“
OF
”表示取消低温保护功能，“
On
”表示开启低
温保护功能。出厂默认值为“
OF
”。
外接温度传感器
（T5200-TB-9JR0, T5200-TF-9JR0)
当温控器接上外置传感器时，内置NTC传感器自动失效。
编码
Code
T
5200
-TC-
9
JS
0
T
5200
-TB-
9
JS
0
T
5200
-TB-
9
JR
0
T
5200
-TF-
9
JS
0
T
5200
-TF-
9
JR
0
参数名
Parameter Name
默认值
Default
功能
Function
01
失电重启
Restart after Power
Failure
00
00：关闭；01：开启；
02：恢复掉电前状态
00：off；01：on；02：keep last status
02
摄氏华氏转换
°F
/℃ C
F：华氏度（
°F
）；C：摄氏度（ ℃）
F：Fahrenheit Degree（
°F
）；
C：Celsius Degree（℃）
03
设定温度上限
Upper limit of set temp
35.0℃
设定范围2～49.5℃
Setting Range 2～49.5℃
04
设定温度下限
Lower limit of set temp
5.0℃
设定范围0～47.5℃
Setting Range 0～47.5℃
05
键盘锁
Keypad lockout
00
00：无锁；01：锁定所有键；02：锁定开关键；
03：锁定除了开关键之外其他键
00：No lock；01：Lock all keys；02：Lock ON/
OFF Key 03：Lock the keys except ON/OFF key
06
屏幕显示
Screen Display
00
00：显示室内温度；01：显示设定温度
00：Display room temp；01：Display set temp
07
自动或手动模式转换
Auto or Manual Mode
Switch
01
00：手动模式转换；01：自动模式转换
00：Manual Mode；01：Auto Mode
08
门卡状态
Key Card Status
01
00：S1、S2短接时代表插卡状态；断开时代表拔卡
状态。
01：S1、S2断开时代表插卡状态；短接时代表拔
卡状态。
00：S1、S2 Short Connection indicates key card is
inserted; Disconnection indicates key card is pulled
out.
01：S1、S2 Disconnection indicates key card is
inserted; Short Connection indicates key card is
pulled out.
09
门卡拔出后制冷温度
Cooling Temp when key
card is pulled out
26.0℃
设定范围22～32℃。
Setting Range 22～32℃。
10
门卡拔出后制热温度
Heating Temp when key
card is pulled out
18.0℃
设定范围10～21℃。
Setting Range 10～21℃。
Functional Code Setting Table
功能编码表
进入参数表：关机状态下同时按住“ ”和“
▲
”键5秒，显示“01”及参数值，之后按“M”键选择要查看的参数，用“
▲
”和“
▼
”修改。
Enable the setting table: hold down the "
" and "
▲
" for 5 seconds, "01" and code appear, after which press 'M' button to select code, use "
▲
" and "
▼
" buttons to adjust the value.
* 失电后温控器重启动，用户可选择重启动，不启动或恢复上次状态
* Power failure memory supports "restart" or "recover to previous status" after power resume
