TEC2101-3 N2 Networked Single-Stage Thermostat Installation Instructions 5
The Controller Point Type is the fixed-point definition
inside the controller. The BAS Model Point type is the
definition inside the model file. Use an NCM CS object
to retrieve the data.
The most recent N2 command received by any of the
N2 Bus Objects listed in Table 1 controls the
thermostat.
Setback Cooling SP
1,2
(Unoccupied Cooling SP)
ADI-6 N2 AO CSAD 54 to 100°F
(12 to 37.5°C)
Minimum Heat SP ADI-7 N2 AI CSAD 40°F (4.5°C)
Maximum Heat SP
1
ADI-8 N2 AO CSAD 40 to 90°F (4.5 to 32°C)
Minimum Cool SP
1
ADI-9 N2 AO CSAD 54 to 100°F
(12 to 37.5°C)
Maximum Cool SP ADI-10 N2 AI CSAD 100°F (37.5°C)
Fan
1
BD-1 N2 BO CSBD 0 = Auto
1 = On
Mode
1
BD-2
N2 MSO
3,4
CSMS 0 = Off
1 = Cool
2 = Heat
3 = Auto
Occupancy
1
BD-3 N2 BO CSBD 0 = Unoccupied
1 = Occupied
W1 State BD-4 N2 BI CSBD 0 = Off
1 = On
Y1 State BD-6 N2 BI CSBD 0 = Off
1 = On
G State - Fan BD-8 N2 BI CSBD 0 = Off
1 = On
Temp Units
1,5
(Local Display Only)
BD-9 N2 BO See Footnote 5. 0 = °C
1 = °F
Occupancy Override BD-10 N2 BI CSBD 0 = No Override
1 = Override
DI1
6,7
BI-1 N2 BI CSBI 0 = Off
1 = On
Temp Alarm
6
BI-2 N2 BI CSBI 0 = Normal
1 = Alarm
DI2
6,7
BI-3 N2 BI CSBI 0 = Off
1 = On
1. Commandable.
2. The Heating and Cooling Setpoint (SP) cannot be overridden simultaneously (this also applies to the Setback Heating SP
and Setback Cooling SP). The overridden setpoint must be released prior to overriding the other setpoint. Additionally, if
one setpoint is overridden, the other setpoint may be automatically adjusted by the TEC2101-3 thermostat to maintain the
minimum deadband between the two setpoints.
3. The Multiple Command Output (MCO) object is used to schedule multiple Multi-State Objects (MSOs).
4. When defining the N2 MSO, select TEC Mode from the States Text Menu. Type 4 for the TEC2101-3 thermostat.
5. On the Metasys Network Control Module (NCM) system, map BD-9 Temp Units Mode as a Binary Output (BO) object with
Auto Restore and Local Control set.
6. Can be a Change-of-State (COS) alarm to the BAS or N2 Dialer Module (NDM) to initiate a dial-out.
7. The state of DI1 and DI2 is communicated over the N2 network even if the digital inputs are configured as None through the
local interface at the thermostat.
Table 1: N2 Bus Objects (Part 2 of 2)
Point Name Thermostat Point
(Type/Address)
N2 Bus Object
Type
Model Point Type Range
