Configuring occupancy

To adapt to nearly any application, the TEC3000 controller

supports a wide variety of occupancy sources, such as:

• Local stand-alone weekly scheduler

• Remote schedule from BAS

• Occupancy sensor (internal or remote)

• Occupancy binary input (configurable)

• Manual occupancy override

• Temporary occupancy (by interacting with the screen

while in unoccupied mode)

• Temporary occupancy binary input

Occupancy is determined using a top-down decision

matrix as shown in Table 9.

Enumerations may not match the TEC3000 Series

Networked and Wireless Proportional Fan Coil and Individual

Zone Thermostat Controllers with Dehumidification Capability

Installation Instructions (LIT-12013162)and the TEC3000

Series Field-Selectable BACnet MS/TP or N2 Networked

Thermostat Controllers Technical Bulletin (LIT-12011956)for

NAE releases prior to 7.x.

Table 9: Occupancy determination

Sequence of operation (highest to lowest priority) Status indicated

Manual

Occupancy

Mode

(OCCOVRD-

MODE)

Occupancy BI

(BI1‑S, BI2‑S)

2, 3

Temporary

Occupancy

Schedule (External

or Schedule)

(OCC‑CONFIG,

NET‑OCC)

Motion

Sensor

Effective

Occupancy

(EFF‑OCC)

Occupancy Source

(OCCSOURCE‑S)

Occupied Occupied-

Override

Unoccupied

–

Unoccupied-

Override

Occ Override

Closed

Occupied

Open

– –

Unoccupied

Occupancy BI

True

NOT Occupied Temp Occupancy Temp Occ

True

NOT Occupied

–

Temp Occupancy Temp Occ BI

True Occupied

False Standby

Occupancy SensorOccupied

Disabled Occupied

Unoccupied Unoccupied

Standby

–

Standby

Occupancy Schedule

True Occupied

False Unoccupied

Occupancy Sensor

No Override

Not Configured

False

Not Set

Disabled Occupied Occupancy Schedule

1 Not Configured means that neither BI1 Config nor BI2 Config is set to Occupancy BI. Open and Closed refer to the current state of

the BI when configured as Occupancy.

2 True is triggered by interacting with the screen during a scheduled unoccupied period. A value of True can only occur when the

schedule is not Occupied.

3 When triggered by a BI configured for Temp Occ, the input is ignored when the schedule is Occupied, the Manual Occupancy Mode

is notNo Override, or an Occupancy BI is configured.

4 Built-in occupancy sensing (PIR) or BI configured for Motion NO or Motion NC.

5 Not Set occurs when no events are scheduled through the local scheduler, or the schedule source is set to Schedule and the

Schedule is writing Not Set as the schedule.

Selecting schedule source

Scheduling (for networked models)

The TEC3000 Thermostat Controller can operate as a

stand-alone unit with an internal schedule or scheduled

with an external schedule. The OCC-CONFIG object sets

the method used for scheduling.

If the OCC-CONFIG is set to External, the NET-OCC object

is used to control the unit externally.

If the OCC-CONFIG is set to Schedule, the internal

schedule commands the LOCAL-OCC object, which sets

the Occupancy Schedule command.

Note: If you do not have a schedule in the

Schedule object and you have the OCC-CONFIG

set to Schedule, you can control the unit with the

LOCAL-OCC object externally; however, we do

not recommend this method. See Table 10 for

scheduling information.

Once the Occupancy Schedule command is set, the

settings shown in the occupancy determination table

determine the effective occupancy. See Table 9.

TEC3000 Series Proportional Fan Coil Thermostats Installation Guide 19
