Maintenance - 43
SPARK PLUGS
Inspect spark plugs periodically. Replace if elec-
trodes are badly worn, insulators are cracked, or if
they are badly fouled.
To remove spark plugs, twist and remove all spark
plug leads. Unscrew spark plug from cylinder head.
To install spark plugs, wipe spark plug seats clean
with a clean rag. Install spark plugs finger tight, then
tighten to specified torque. Refer to Engine Speci-
fications.
IMPORTANT: Avoid engine damage by installing
spark plugs into COOL cylinder head and not over-
tightening.
Before installing the spark plug lead, apply a light
coat of
Triple-Guard
grease to the ribbed portion of
the spark plug. This will help prevent corrosion be-
tween the spring terminal and the spark plug.
1. Ribbed portion of the spark plug
PROPELLER
IMPORTANT: Apply
Triple-Guard
grease to the en-
tire propeller shaft before installing the propeller. At
least annually, remove the propeller and check for
debris. Clean the shaft and regrease it before rein-
stalling a propeller.
Installation
Slide thrust washer onto shaft with shoulder facing
aft.
Slide propeller onto shaft, engaging the splines and
seating it on the thrust washer.
Slide spacer onto the shaft and engage the propel-
ler shaft splines.
Wedge a block of wood between the propeller
blade and the anti-ventilation plate.
WARNING
The ignition system presents a serious
shock hazard. The primary circuit operates
in excess of 250 volts; the secondary circuit
operates in excess of 25,000 volts. Use cau-
tion to avoid injury from shock or injury
resulting from your reaction to shock. Do
not handle primary or secondary ignition
components while the engine is cranking or
running.
WARNING
When servicing the propeller, always shift
the outboard to NEUTRAL position, turn the
key switch OFF and disconnect battery neg-
ative (–) cable so the engine cannot be
started accidentally.
