12 - General Information
ENGINE SPECIFICATIONS
90, 115 Models
Displacement 105.4 cu. in. (1726 cc)
Engine Type Two-Cycle, 60° V, 4 Cylinder
Loop-Charged
Full Throttle Operating Range 4500 to 5500 RPM
Power
(1)
90 – 90 HP (67.2 kw) @ 5000 RPM
115 – 115 HP (85.8 kw) @ 5000 RPM
Idle RPM in Gear
(2)
650 ± 50
Ignition Timing –Idle
(2)
W.O.T.
4° ± 1°
20° ± 1°
Emission Control System:
per SAE J1930
(2)
EM (Engine Modification)
Fuel Requirements
(2)
87 Pump Posted AKI (90 RON) – Refer to Fuel and Oil
Oil Supplied by oil injection system
Warning Signals Engine Overheat, Low Oil, No Oil
Ignition Features
QuikStart™
and
S.L.O.W.™
Battery, Minimum 360 CCA (465 MCA)
OR 50 ampere-hour, 12 volt
Spark Plug
(2)(3)
Torque
Refer to ECI Label
18 to 21 ft. lbs. (24 to 28 N·m)
Fuses P/N 514021
Fuel Filter P/N 433190
Alternator 20-Amp, Fully Regulated
Gearcase – Lubricant
Capacity
Evinrude/Johnson Ultra-HPF™
gearcase lubricant
PL, VL Models – 26 fl. oz. (770 ml)
PX Models – 44 fl. oz. (1300 ml)
Pwr. Trim/Tilt – Fluid Capacity 21 fl. oz. (622 ml)
Propeller
(4)
Refer to Propeller Selection
Fuel Tank
(4)
Capacity – 6 U.S. gallons (22.7 liters)
Weight
(5)
L Models – 335 lbs. (152 kg)
X Models – 352 lbs. (160 kg)
Sound at Driver’s Ear
(LpA) ICOMIA 39.94
80.8 dB(A)
Transom Height L Models – 19 1/2 to 20 in. (495 to 508 mm)
X Models – 24 1/2 to 25 in. (622 to 635 mm)
