Jonsered CS 2186 User Manual

English – 39
TECHNICAL DATA
Bar and chain combinations
The following combinations are CE approved.
Saw chain filing and file gauges
EC-declaration of conformity
(Applies to Europe only)
Jonsered, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declares under sole responsibility that the chain saws Jonsered
CS 2186 and CS 2186WH from 2002’s serial numbers and onwards (the year is clearly stated in plain text on the type plate with
subsequent serial number), are in conformity with the requirements of the COUNCIL’S DIRECTIVES:
- of June 22, 1998 ”relating to machinery” 98/37/EC, annex IIA.
- of May 3, 1989 ”relating to electromagnetic compatibility” 89/336/EEC, and applicable supplements.
- of May 8, 2000 ”relating to the noise emissions in the environment” 2000/14/EC.
For information relating to noise emissions, see the chapter Technical data. The following standards have been applied: EN292-2,
CISPR 12:1997, EN608.
Notified body: 0404, SMP Svensk Maskinprovning AB, Fyrisborgsgatan 3, SE-754 50 Uppsala, Sweden, has carried out EC type
examination in accordance with the machinery directive’s (98/37/EC) article 8, point 2c. The certificates for EC type examination
in accordance with annex VI, have the numbers: 404/02/884 – Jonsered CS 2186/ CS 2186WH.
In addition, SMP, Svensk Maskinprovning AB, Fyrisborgsgatan 3, SE-754 50 Uppsala, Sweden, has certified conformity with annex
V of the Council’s Directive of May 8, 2000 ”relating to the noise emissions in the environment” 2000/14/EC. The certificate has the
number: 01/161/036 – Jonsered CS 2186/ CS 2186WH.
The supplied chain saw conforms to the example that underwent EC type examination.
Huskvarna 11 June 2002
Bo Andréasson, Development manager
Bar Chain
Length, inch Pitch, inch Gauge, mm Max. nose radius Type Length, drive links (no.)
18 3/8 1,5 11T Jonsered H42 56
20 3/8 11T 60
24 3/8 11T 68
28 3/8 11T 72
