KEY TO SYMBOLS
English
–
7
1155356-93 Rev.2 2014-04-15
Symbols on the machine:
WARNING! Chain saws can be
dangerous! Careless or incorrect use
can result in serious or fatal injury to the
operator or others.
Please read the operator’s manual
carefully and make sure you
understand the instructions before
using the machine.
Always wear:
• Approved protective helmet
• Approved hearing protection
• Protective goggles or a visor
This product is in accordance with
applicable EC directives.
Noise emission to the environment
according to the European
Community’s Directive. The machine’s
emission is specified in the Technical
data chapter and on the label.
Chain brake, activated (right) Chain
brake, not activated (left)
Ignition; choke:
Set the choke control
in the choke position. This should
automatically set the stop switch to the
start position.
Air purge
Refuelling.
Chain oil fill.
Adjustment of the oil pump.
Other symbols/decals on the machine refer to special
certification requirements for certain markets.
Symbols in the operator’s
manual:
Switch off the engine before
carrying out any checks or
maintenance. CAUTION! The start/
stop switch automatically returns to
run position. In order to prevent
unintentional starting, the spark plug
cap must be removed from the spark
plug when assembling, checking
and/or performing maintenance.
Always wear approved protective
gloves.
Regular cleaning is required.
Visual check.
Protective goggles or a visor must be
worn.
Refuelling.
Filling with oil and adjusting oil flow.
The chain brake must be engaged
when the chain saw is started.
WARNING! Kickback may occur when
the nose or tip of the guide bar touches
an object, and cause a lightning fast
reverse reaction, kicking the guide bar
up and towards the operator. May cause
serious personal injury.
