38 – English
TECHNICAL DATA
Recommended cutting equipment for USA
Following is a list of recommended cutting equipment for the Jonsered chain saw models CS 2258, CS 2260 and CS
2260WH.
The combinations of power head, bar and chain have been investigated in accordance with the kickback and vibration
requirements of ANSI B175.1–2000.
The guide bar nose radius is determined by either the maximum number of teeth in the nose sprocket or the
corresponding maximum nose radius of a solid bar.
The following list is the chain saw manufacturers recommendations. There may be other combinations available, which
will also achieve kickback reduction.
As we are listing the maximum guide bar nose radius, you may use a guide bar with smaller nose radius than in our list.
For guide bars of the same length, all sprocket-nose guide bars of the same pitch and having the same number of
sprocket teeth may be considered to have equivalent kickback energy. A hard nose bar having the same length and nose
radius as a sprocket-nose bar may be considered to have equivalent or less kickback energy than the sprocket-nose bar.
Low kickback saw chain is a chain which has only met the kickback performance requirements of ANSI B175.1 safety
requirements for gasoline powered chain saws when tested on the representative sample of chain saws below 3.8 cu.
in. specified in ANSI B175.1. We recommend that you as a replacement use the listed chains or "Low kickback saw
chains" which are available at your dealer.
The following cutting attachments are approved for the models Jonsered CS 2258, CS 2260 and CS 2260WH.
Note: For guide bars with nominal length 20” and with pitch 0.325”, two different drive link counts exist. Always check
information on the guide bar to get the correct drive link count for a spare saw chain.
Saw chain filing and file gauges
Note: For the chains above you are free to choose between 0.050" and 0.058" gauge drive link for the corresponding
bar, see the table below.
Guide bar Saw chain
Length, inch Pitch, inch Gauge, inch
Max. nose
radius
Type
Drive link
count
13
0.325
0.058
10T
Jonsered H25
56
15 64
16 66
18 72
20 12T 78/80
15
3/8 11T Jonsered H42
56
16 60
18 68
0.050"/1,3 mm H23 H46
0.058"/1,5 mm H25 H42
