Joyor A3 User Manual

Display:
Display Cables:
Brake cable:
(red connector): red +5V, white Vout, black GND
Accelerator cable:
(white connector): red +5V, green Vout, black GND
Lights cable:
(black connector): red led+(12V), black – front light led
LCD Display connecting cable:
yellow SW, red +12V, black GND, blue TX, green RX

Joyor A3 Specifications

General

Brand	Joyor
Model	A3
Category	Scooter
Language	English
