JUKI DDL-8700B-7 Quick Guide

By providing a presser foot with a higher lift (13mm), a
light-touch stitch dial, a throat plate with marker grooves
that can be used as guide for seam allowance, and
other easy-to-operate functions, the burden on the
operator is lightened, and productivity is further
increased.
13mm
13mm
13mm
The machine comes with a
thread trimming mechanism
that performs speedy and
reliable thread trimming to
achieve highly efficient sewing
work.
Stitch dial
Stitch dial
Stitch dial
The DDL-8700B-7 is the most reliable,
sophisticated model developed in-house at JUKI.
The machine has easy-to-operate functions
to achieve improved operability.
The machine is provided as
standard with extra attachment
mounting seats for attachment
of new auxiliary parts in the
future. The extremely high
durability of the seats ensures
an extended service with
frequent replacement of
attachments.
The machine provided as standard with
attachment mounting seats.
The hinge is located as such
so as to prevent the material
from being caught by it,
thereby improving workability.
The location of the hinge to prevent the sewing
material from being caught by the hinge.
By thoroughly investigating and modifying the
sewing mechanisms in order to achieve low-tension
sewing, the machine flexibly responds to various kinds
of materials and produces beautiful seams of consistent
quality.
Sewing mechanism that demonstrates outstanding
responsiveness to materials to be sewn.
Reliable thread trimming mechanism.
＊
The function marked with a triangle (
▲
) is available on custom order.
Main function
Production support function
(Bobbin thread counter,thread counter,etc.)
Operation panels
0~15 stitches
●
●
●
Automatic reverse-feed stitching
(performed at start/end of sewing; selectable)
0~15 stitches
Double reverse-feed stitching
(performed at start/end of sewing; selectable)
0~999 stitches,
0~15 stitches
Constant-dimension sewing
(performed at start/end of sewing; selectable)
0~99 stitches,
0~15 stitches
Rectangular stitching
(performed at start/end of sewing; selectable)
Automatic sewing (constant-dimension sewing and
the rectangular stitching can be selected)
Changeover the stop position between needle-up
position and needle-down position
0~15stitches,
0~15times
Multi-layer stitching
Needle up/down compensation stitch
One shot
Soft start function on/off
Thread trimmer on/off feature
ISS function (IT10, IT100)
●
●
●
●
●
▲
Needle up/down correction (1 stitch stroke or
needle up/down according to the internal setting)
(changeable between "up
→
down" and "down
→
up")
Multi-function panel
