– 5 –
Adjustment procedures
Results of Improper adjustment
1. Set the stitch dial to “0”.
2. Turn the handwheel to bring the height of the feed dog
3
to
the maximum. (Bring the needle bar to the lowest dead point of
its stroke.)
3. Loosen clamping screw
1
of the vertical feed front arm.
4. Turn the vertical feed front arm
2
to adjust the height of the
feed dog
3
from top surface of the throat plate
4
to the dimen-
sion A. Then securely tighten clamping screw
1
of the vertical
feed front arm.
When the height of the feed dog
3
is higher than the specied value :
o
Stitch pitch becomes larger than
the scale of the feed dial.
o
Balloon stitches will result.
o
Return of sewing product will oc-
cur.
o
The feed dog
3
comes in con-
tact with the knife, and the knife
and the feed dog
3
may be
damaged.
When the height of the feed dog
3
is lower than the specied value :
o
Stitch pitch becomes smaller
than the scale of the feed dial.
o
Feed force will be deteriorated.
Adjustment procedures
Results of Improper adjustment
1. Loosen two setscrews
1
of the hook.
2. Draw out hook
2
in the direction of the arrow.
3. Replace the washer
3
to adjust so that the clearance between
throat plate
4
and top surface of hook stopper section of hook
2
is dimension A.
(Refer to "4. Selective parts and consumable parts" about the
types of washer.)
4. Align the notched section of hook shaft
5
and No. 1 screw of
setscrews
1
of the hook. Then tighten two setscrews
1
of the
hook.
o
Stitch skipping or thread break-
age will result.
o
Needle breakage will result.
o
Irregular stitches will result.
