– 40 –
3. Portion to which LOCKTITE is applied
LOCKTITE has been applied to the following parts at the time of assembly at the factory.
Avoid disassembling these parts to the most. When an assembly which includes the aforementioned parts
has been forced to be disassembled, be sure to wash the LOCKTITE applied part using a paint thinner or the
like, and reassemble it using LOCKTITE after removing any moisture from the mating faces.
If it is hard to remove a part which has been xed using LOCKTITE, heat it using a torch lamp or the like to
help remove the part.
No. Portion to which LOCKTITE is applied Part No. LOCKTITE No.
1 Set screw of coupling SM8050812TP LOCKTITE #243
No. 1
Setscrews of coupling
LOCKTITE applied
Coupling
海外講習会用121122LU-2810(-7)EM
