MB-1800B, 1800A/BR10 (September, 2003) 1/4
,,,,,,,, ,,,,,,,,
,,,
● The machine has 55 different stitching patterns as standard. In addition to the
sewing shapes, the buttonhole intervals and number of stitches can also be
changed on the operation panel. The machine completely supports many
different button specifications to increase its range of applicability, reduce costs
associated with changes in specifications, and save the operator from having to
adapt the machine to different specifications.
● The machine performs thread trimming at the optimal position by correcting the
button position with respect to the needle entry of the last stitch. This shortens
the thread remaining on the material after thread trimming to approx. 3.5mm.
● The machine comes as standard with the solenoid-operated, thread-tension-
changeover "thread-fray-prevention function. " Since the machine is designed
to use a long needle (TQ×7), the "thread-fray-prevention function" can be used
for sewing shank buttons.
● The machine head is a non-lubricating type. With this type, the operator never
has to add oil, and staining of the sewing product with oil is an impossibility.
Computer-controlled, Dry-head, High-speed, Single-thread,
Chainstitch Button Sewing Machine
MB-1800B
(with wiper unit)
MB-1800B
MB-1800A/BR10
● The three different operation modes available are the automatic button feeding
mode in which the machine continuously feeds the buttons in the feeder bowl,
the non-feed mode in which the operator manually places the buttons in the
sewing position one by one, and the small-lot sewing mode in which the
operator sets the buttons in place for one garment (five or six buttons) in
advance, upon which the buttons are automatically and continuously fed to the
sewing position. As a result the machine can employed by a small-lot
production system by selecting the appropriate operation mode.
● The machine is provided with a wider sewing area to facilitate garment setting,
and allows the operator to check the remaining quantity of buttons while
remaining seated, thereby enhancing ease of operation. Furthermore, the
machine allows the operator to continuously sew buttons with pedal depressed,
thereby helping reduce the operator's fatigue.
MB-1800A/BR10
(with button feeder)
SPECIFICATIONS
Model name
Max. sewing speed
Amount of feed
Applicable button
Stitching shape
Wiper unit
Lift of the button clamp
Needle bar stroke
Needle (at the time of delivery)
Feed system
Knot-tying mechanism
Lubrication
Discrimination of button
to be feed
Button feed
Button feed mode
Power requirement
Power consumption
Weight
Crosswise feed 0
〜
10mm/Lengthwise feed 0
〜
6.5mm
Type: Round-shaped flat button
Size: φ10
〜
φ28mm
Attachment: • For small button (φ10
〜
φ12mm)
• For medium button (φ12
〜
φ20mm)
• For large button (φ20mm or more)
Thickness: 1.8
〜
5mm
• The button clamp jaw lever for thick button
has to be used for buttons with thicknesses of
3.5mm or more.
Type: Shank button, wrapped-around button, snap,
metal button, stay button, label (exclusive
attachments have to be used.)
Crosswise feed 0
〜
4mm/Lengthwise feed 0
〜
4mm
Type: Round-shaped flat button
Size: φ9
〜
φ26mm
• Machines can be custom ordered for the sewing of
button diameters outside the standard range less
than φ10mm and less, φ19mm and over.
• For button of which diameter is φ16mm or more,
a button clamp jaw lever for large buttons has to be
used.
Thickness: 1.8
〜
3.5mm
―
―
―
Single-phase 220〜240V, 100〜120V
(by changing over the PWB connector)
150W
Machine head, circuit board 25kg
Vibration system
By the horizontal, forced feed mechanism
Automatic feed mode, non-feed mode,
and small-lot sewing mode
Single-phase 100V, 115V, 200V, 220V, 240V
250W
Machine head, circuit board + control box for BR
+ device + table 56.5kg
MB-1800S MB-1800B MB-1800A/BR10
1,800rpm
Options Provided as standard
Max. 14mm
48.6mm
TQ×7 (#16) #14〜#20
By stepping motor
Provided as standard
No lubrication
