JUKI MO-50e User Manual

4
4
1
6
5
- Place the spool on the
spool holder pin.
- Bring thread up through guide (1).
-
- Thread guide (4,5).
- Thread left needle eye (6)
- Place thread under presser foot.
Pull the tdhread under the
protector (2) and pass under the
guider up to go around the
pre-tension (3).
Note:
If the lower looper has to be re-
threaded, cut both needle threads off
at the needle eye and remove
surplus thread from below. Thread
the looper and then re-thread the
needles.
When threading is complete, lower
the presser foot and close the
looper cover and cloth plate.
Left needle (Yellow)
After threading
Threading
2
3

JUKI MO-50e Specifications

General

Type	Overlock
Number of Threads	3/4
Stitch Length	1 - 4 mm
Differential Feed Ratio	0.7 - 2.0
Maximum Sewing Speed	1300 stitches per minute
Needle System	130/705H
Presser Foot Lift	5 mm
Motor Power	90 W
Needle Size	11-14
