Manual No. PT9804-GR Adjusting Instructions & Illustrated Parts List for
35800 Series Machines
2
PREFACE
This parts manual has been prepared to assist you in locating individual parts or assemblies on 35800 Series machines.
It is the desire of Union Special that each machine run at its optimum performance. Parts listed in this manual are designed
specifically for your machine and are manufactured with utmost precision to assure long lasting service.
This manual has been comprised on the basis of available information. Changes in design and/or improvements may
incorporate a slight modification of configuration in illustrations or part numbers.
On the following pages are illustrations and terminology used in describing the parts used on 35800 Series machines.
First Edition Copyright 2007
By
Union Special Corporation Rights Reserved In All Countries
Printed in U.S.A. August 2007
DENTIFICATION OF MACHINES
Each UNION SPECIAL machine is identified by a style number, which is stamped into the style plate affixed to the middle of the
machine under the tension assembly.
The serial number is stamped on a plate attached to the right rear top of the machine.
