Image4: Setting the temperature limit (before/after)
￭ Pull the control knob off the central plate so that the adjustment rings are vis-
ible Bild.
Pulling off is done by hand or with a suitable tool, e.g. vacuum lifting tool or
key cap puller.
￭ Turn the large blue adjustment ring clockwise to the desired minimum temper-
ature. Each notch corresponds to a change of about 2°C.
￭ Turn the small red adjustment ring anticlockwise to the desired maximum tem-
perature.
The respective adjustment ring can only be turned in one direction. To return
to the original setting, continue turning to the respective position.
￭ Replace the control knob, observing the coding (Fig. 4, bottom) of the control
knob and rotary axle.
8 Technical data
Rated voltage AC 220 ... 240 V ~
Floor thermostat
8 / 9
82404903 16.09.2022
J0082404903

Jung FTR231 Specifications

General

Brand	Jung
Model	FTR231
Category	Thermostat
Language	English
