JVC AV-14A3 User Manual

No. 52029
A
V-14A3
A
V-1415EE
A
V-14AMG3
36
EXPLODED VIEW PARTS LIST
! Ref.No. Part No. Part Name Description
!
!!
!
V01 A34JXV70X PICTURE TUBE AV-14A3
!
!!
! V01 A34JXV70X PICTURE TUBE AV-14A3/AU
!
!!
! V01 A34JXV70X PICTURE TUBE AV-14A3/HK
!
!!
!
V01 A34AGT13X PICTURE TUBE AV-1415EE
!
!!
!
V01 A34JXV70X PICTURE TUBE AV-14AMG3
!
!!
!
V01 A34JXV70X PICTURE TUBE AV-14AMG3/-A
!
!!
! L01 QQW0096-001 DEG COIL or CELD025-005J6 AV-14A3
!
!!
! L01 QQW0096-001 DEG COIL or CELD025-005J6 AV-14A3/AU
!
!!
! L01 QQW0096-001 DEG COIL or CELD025-005J6 AV-14A3/HK
!
!!
!
L01 QQW0093-001 DEG COIL --- AV-1415EE
!
!!
!
L01 QQW0096-001 DEG COIL or CELD025-005J6 AV-14AMG3
!
!!
! L01 QQW0096-001 DEG COIL or CELD025-005J6 AV-14AMG3/-A
!
!!
! DY01 CE20301-00A DEF YOKE AV-14A3
!
!!
! DY01 CE20301-00A DEF YOKE AV-14A3/AU
!
!!
!
DY01 CE20301-00A DEF YOKE AV-14A3/HK
!
!!
!
DY01 QQD0046-001 DEF YOKE AV-1415EE
!
!!
! DY01 CE20301-00A DEF YOKE AV-14AMG3
!
!!
! DY01 CE20301-00A DEF YOKE AV-14AMG3/-A
!
!!
! T1522 QQH0108-001 F.B.TRANSF. AV-14A3
!
!!
!
T1522 QQH0108-001 F.B.TRANSF. AV-14A3/AU
!
!!
!
T1522 QQH0108-001 F.B.TRANSF. AV-14A3/HK
!
!!
! T1522 QQH0132-001 F.B.TRANSF. AV-1415EE
!
!!
! T1522 QQH0132-001 F.B.TRANSF. AV-14AMG3
!
!!
! T1522 QQH0132-001 F.B.TRANSF. AV-14AMG3/-A
!
!!
!
1 LC10164-027A-H FRONT CABINET AV-14A3
!
!!
!
1 LC10164-027A-H FRONT CABINET AV-14A3/AU
!
!!
!
1 LC10164-027A-H FRONT CABINET AV-14A3/HK
!
!!
! 1 LC10164-028A-H FRONT CABINET AV-1415EE
!
!!
! 1 LC10164-029A-H FRONT CABINET AV-14AMG3
!
!!
!
1 LC10164-029A-H FRONT CABINET AV-14AMG3/-A
2 A 48 45 7 -3 -H S PR IN G
3 CHGB0016-0A BRAIDED ASSY
4 CE40305-00B PC MAGNET or CE42511-00A
5 QAS0016-001 SPEAKER
! 6 LC30345-001A-H SP HOLDER
7 C E4 21 5 3- 00 A J1 W ED GE AS SY ( X3 )
!
8 LC30347-003A-H CONTROL KNOB
! 9 LC30348-003A-H POWER KNOB
! 10 LC30346-001B-H REMOCON LENS
! 11 CM48144-002-H PB STOPPER
!
!!
!
12 QMPR340-165-K2 POWER CORD AV-14A3
!
!!
!
12 QMPG090-165-K2 POWER CORD AV-14A3/AU
!
!!
! 12 QMPR370-165-E2 POWER CORD AV-14A3/HK
!
!!
! 12 QMPR340-165-K2 POWER CORD AV-1415EE
!
!!
! 12 QMPR340-165-K2 POWER CORD AV-14AMG3
!
!!
!
12 QMPR380-165-K2 POWER CORD AV-14AMG3/-A
!
13 CM47005-A01-H CORD CLAMP
! 14 LC10165-001D-H REAR COVER
15 QYSBSFG4016Z TAP SCREW (X4)
16 QYSBSF3010Z TAP SCREW (X1)
17 QYSBSBG4012M TAP SCREW (X1)
!
18 GG20024-001A-H RATING LABEL
