AV-14AT
No. 56088 3
SPECIFICATIONS (Page 2)
Item Content
Dimensions (W × H × D) 364mm × 333.5mm × 374mm
Mass 9.3kg
TV RF System B / G, I, D / K, K1
Colour System TV Mode PAL / SECAM
VIDEO Mode PAL / SECAM / NTSC3.58 / NTSC4.43
Receiving Frequency VHF (VL) 46.25MHz ~ 168.25MHz
VHF (VH) 175.25MHz ~ 463.25MHz
UHF 471.25MHz ~ 863.25MHz
CATV ● Cable TVs of Mid (X-Z, S1-S10)
Super (S11-S20) & Hyper (S21-S41) bands receivable
Intermediate VIF Carrier 38.0MHz
Frequency 31.5MHz (6.5MHz)
SIF Carrier 32.0MHz (6.0MHz)
32.5MHz (5.5MHz)
33.5MHz (4.5MHz)
Colour Sub Carrier Frequency PAL (4.43MHz)
SECAM (4.40625MHz / 4.25MHz)
NTSC (3.58MHz / 4.43MHz)
Aerial Input Terminal 75Ω Unbalanced
Power Input AC110 ~ 240V, 50/60Hz
Power Consumption 70W, 0.60A (at 220V)
Picture Tube Visible size : 34cm measured diagonally
High Voltage 22.5kV ± 1.5kV (at zero beam current)
Speaker 8cm Round type
Audio Output 3W (Monaural)
Input Video 1Vp-p, 75Ω
Audio 500mVrms (−4dBs), High impedance
Output Video 1Vp-p, 75Ω
Audio 500mVrms (–4dBs), Low impedance
Headphone Jack Stereo mini jack (3.5ø)
Remote Control Unit RM-C360-1H (Battery size : AA/R06/UM-3 × 2)
Design & specifications are subject to change without notice.
