(No.YA552)3-17
PRINTED WIRING BOARD PARTS LIST [AV-21QMG7/G,AV-21QMG7B/G]
MAIN P.W. BOARD ASS'Y (SCQ-1401A-H2)
 Ref No. Part No. Part Name Description Local
IC401 AN15526A IC
IC601 AN5279 IC
IC701 A8897CPBNG-6RJ2 IC(MCU) (SERVICE)
IC702 ATE08-14UMG7 IC (SERVICE)
IC704 GP1UE281QKVF IR DETECT UNIT
IC921 STR-W6554A-F5 IC
IC951 TL431/A/-T IC
IC971 S78L05-T IC
IC972 PQ050RDA1SZ IC
IC973 PQ090RDA1SSH IC
Q101 2SC5397/CD/-T TRANSISTOR
Q102 UN2212-X DIGI TRANSISTOR
Q103 2SA812A/5-6/-X TRANSISTOR
Q104 2SC1623A/5-6/-X TRANSISTOR
Q351 2SC4212/Z1/ TRANSISTOR
Q352 2SC4212/Z1/ TRANSISTOR
Q353 2SC4212/Z1/ TRANSISTOR
Q354 2SA812A/5-6/-X TRANSISTOR
Q421 2SC1623A/5-6/-X TRANSISTOR
Q422 2SC1623A/5-6/-X TRANSISTOR
Q461 RDN050N20 POWER MOS FET
Q521 2SC2655/Y/-T TRANSISTOR
Q522 TT2202-YD POW TRANSISTOR
Q571 2SA1208/ST/Z1-T TRANSISTOR
Q572 UN2226-X DIGI TRANSISTOR
Q601 2SA812A/5-6/-X TRANSISTOR
Q602 2SA812A/5-6/-X TRANSISTOR
Q603 DTC323TK-X DIGI TRANSISTOR
Q604 2SC1623A/5-6/-X TRANSISTOR
Q605 2SC1623A/5-6/-X TRANSISTOR
Q710 2SA812A/5-6/-X TRANSISTOR
Q711 2SA812A/5-6/-X TRANSISTOR
Q801 KTA1267/YG/-T TRANSISTOR
Q802 UN2226-X DIGI TRANSISTOR
Q981 2SC1623A/5-6/-X TRANSISTOR
D101 1SS355W-X DIODE
D354 MA111-X SI DIODE
D355 MA111-X SI DIODE
D356 MA111-X SI DIODE
D357 MA111-X SI DIODE
D423 1N4003SG-T2 SI DIODE
D424 1SR35-400A-T2 SI DIODE
D520 MA111-X SI DIODE
D521 RH3G-F1 SI DIODE
D522 RU4AM-LFM1 SI DIODE
D523 FR105GT-T3 SI DIODE
D530 FR105GT-T3 SI DIODE
D551 FR105GT-T3 SI DIODE
D552 FR105GT-T3 SI DIODE
D554 MA8091/H/-X Z DIODE
D571 MA8075/H/-X Z DIODE
D581 FR105GT-T3 SI DIODE
D591 1SR35-400A-T2 SI DIODE
D601 MA111-X SI DIODE
D602 MA111-X SI DIODE
D603 MA111-X SI DIODE
D701 MPR3338ST-T16 LED POWER
D710 MA8039/H/-X Z DIODE
D711 MA8091/H/-X Z DIODE
D712 MA8091/H/-X Z DIODE
D713 MA8091/H/-X Z DIODE
D714 MA111-X SI DIODE
D715 MA8091/H/-X Z DIODE
D716 MA8051/M/-X Z DIODE
D717 MA8051/M/-X Z DIODE
D718 MA8051/M/-X Z DIODE
D719 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
D720 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
D721 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
D722 MA111-X SI DIODE
D901 GSIB460-S1 BRIDGE DIODE
D902 FR105GT-T3 SI DIODE
D903 FR105GT-T3 SI DIODE
D904 MA8110/M/-X Z DIODE
D905 MTZJ9.1B-T2 Z DIODE
D906 MTZJ9.1B-T2 Z DIODE
D907 MTZJ9.1B-T2 Z DIODE
D908 MTZJ9.1B-T2 Z DIODE
D909 MTZJ36A-T2 Z DIODE
D951 RU3AM-LFC4 SI DIODE
D952 FR105GT-T3 SI DIODE
D953 FR105GT-T3 SI DIODE
D954 FR105GT-T3 SI DIODE
D955 FR105GT-T3 SI DIODE
D956 1SS133-T2 SI DIODE
D957 MA8330/M/-X Z DIODE
D971 MA111-X SI DIODE
D972 MA111-X SI DIODE
D981 MA111-X SI DIODE
D982 MA111-X SI DIODE
C001 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C002 QETN1HM-336Z E CAPACITOR 33uF 50V M
C005 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C006 QETN1AM-477Z E CAPACITOR 470uF 10V M
C007 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C008 QETN1HM-106Z E CAPACITOR 10uF 50V M
C101 NCB31HK-472X C CAPACITOR 4700pF 50V K
C102 QETN1EM-476Z E CAPACITOR 47uF 25V M
C103 NCB31HK-472X C CAPACITOR 4700pF 50V K
C104 NCB31HK-472X C CAPACITOR 4700pF 50V K
C105 NCB31HK-472X C CAPACITOR 4700pF 50V K
C106 NCB31HK-472X C CAPACITOR 4700pF 50V K
C107 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C108 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C109 QETN1CM-477Z E CAPACITOR 470uF 16V M
C111 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C112 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C113 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C351 QFZ0097-103 MM CAPACITOR 0.01uF 1250V K
C352 QETN1CM-477Z E CAPACITOR 470uF 16V M
C354 NDC31HJ-331X C CAPACITOR 330pF 50V J
C355 NDC31HJ-271X C CAPACITOR 270pF 50V J
C356 NDC31HJ-391X C CAPACITOR 390pF 50V J
C357 QETN1AM-477Z E CAPACITOR 470uF 10V M
C422 QCS32HJ-180Z C CAPACITOR 18pF 500V J
C423 NCB31HK-682X C CAPACITOR 6800pF 50V K
C424 QFLC2AJ-683Z M CAPACITOR 0.068uF 100V J
C427 QETM1HM-108 E CAPACITOR 1000uF 50V M
C428 QETN1HM-227Z E CAPACITOR 220uF 50V M
C430 QFLC2AJ-563Z M CAPACITOR 0.056uF 100V J
C431 QFVF1HJ-184Z MF CAPACITOR 0.18uF 50V J
C435 NCF21HZ-334X C CAPACITOR 0.33uF 50V Z
C436 NCF21HZ-334X C CAPACITOR 0.33uF 50V Z
C471 QETN1HM-226Z E CAPACITOR 22uF 50V M
C521 QCB31HK-332Z C CAPACITOR 3300pF 50V K
C522 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C523 QETN1VM-476Z E CAPACITOR 47uF 35V M
C525 QFZ0196-143 MPP CAPACITOR 0.014uF 1.5kV H
C526 QFZ0196-113 MPP CAPACITOR 0.011uF 1.5kV H
C527 QFZ0197-404 MPP CAPACITOR 0.4uF 250V J
C528 QFP32GJ-393 PP CAPACITOR 0.039uF 400V J
C529 QENC2AM-225Z BP E CAPACITOR 2.2uF 100V M
C530 QCB32HK-561Z C CAPACITOR 560pF 500V K
C531 QEZ0195-475Z BP E CAPACITOR 4.7uF 50V M
C532 QETN2EM-106Z E CAPACITOR 10uF 250V M
C533 QFZ0197-105 MPP CAPACITOR 1uF 250V J
C542 QFZ0197-823 MPP CAPACITOR 0.082uF 250V J
C551 QCB32HK-561Z C CAPACITOR 560pF 500V K
C552 QCB32HK-561Z C CAPACITOR 560pF 500V K
C553 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C554 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C555 QFLC2AJ-103Z M CAPACITOR 0.01uF 100V J
C571 QEZ0203-107 E CAPACITOR 100uF 160V M
C572 QETN1CM-107Z E CAPACITOR 100uF 16V M
C573 QETN1VM-476Z E CAPACITOR 47uF 35V M
C581 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C591 QETN1VM-476Z E CAPACITOR 47uF 35V M
C601 QETN1CM-107Z E CAPACITOR 100uF 16V M
C603 QETN1HM-105Z E CAPACITOR 1uF 50V M
C604 QETN1HM-106Z E CAPACITOR 10uF 50V M
C605 QETN1HM-106Z E CAPACITOR 10uF 50V M
C606 QETN1HM-107Z E CAPACITOR 100uF 50V M
C607 QETN1HM-106Z E CAPACITOR 10uF 50V M
C608 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C609 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C610 QETN1HM-106Z E CAPACITOR 10uF 50V M
C611 QETN1CM-477Z E CAPACITOR 470uF 16V M
C701 QETN1CM-107Z E CAPACITOR 100uF 16V M
C702 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C710 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C711 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C712 NDC31HJ-220X C CAPACITOR 22pF 50V J
C713 NDC31HJ-220X C CAPACITOR 22pF 50V J
C714 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C715 QETN1CM-107Z E CAPACITOR 100uF 16V M
C716 NCB31HK-822X C CAPACITOR 8200pF 50V K
C717 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C718 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C719 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
 Ref No. Part No. Part Name Description Local
