Getting Started
EnglishEnglishEnglishEnglishEnglishEnglishEnglish
LVT0686-009B / CA-K1R/CA-K3R(B) / English
CAUTION:
• Make all connections before plugging the System into an AC power outlet.
Connecting the FM Antenna
Using the Supplied Wire Antenna
Using the Coaxial Type Connector (Not supplied)
A 75-ohm antenna with coaxial type connector (IEC or DIN45 325) should be connected to the FM 75-ohm COAXIAL terminal.
If reception is poor, connect the outdoor antenna.
• Before attaching a 75 ohm coaxial lead (the kind with a round wire going to an outdoor antenna), disconnect the supplied
FM Wire Antenna
LEFT
RIGHT
AUX IN ANTENNA
AM
LOOP
AM
EXT
FM75
COAXIAL
GND
LEFT
CAUTION:
SPEAKER IMPEDANCE 6 16 OHMS.
SPEAKERS
RIGHT
FM wire antenna (supplied)
Coaxial cable
FM outdoor antenna
(Not supplied)
