EN47
Controls
1 Diopter Adjustment Control ................. Z pg. 14
2 Lens Cover Open/Close Ring................ Z pg. 16
3 5-Second Recording Button
[5SEC. REC] ......................................... Z pg. 20
4 Power Zoom Lever [T/W] ..................... Z pg. 18
5 Picture Stabilizer Button
[P.STABILIZER] ..................................... Z pg. 20
6 Program AE Button [P.AE]..................... Z pg. 22
7 Fade/Wipe Button [EFFECT] ................. Z pg. 21
8 •Rewind Button [ 2 , REW] ................ Z pg. 36
•Retake Rewind Button [RETAKE R]..... Z pg. 19
•Quick Review Button [ R] ............. Z pg. 19
9 •Fast-Forward Button [ 3 , FF] ............ Z pg. 36
•Retake Forward Button [RETAKE F] .... Z pg. 19
0 Stop Button [5, STOP] ......................... Z pg. 36
! Play/Pause Button
[ 4 /6, PLAY/PAUSE]............................. Z pg. 36
@ Select Dial [+, –, PUSH] ................ Z pg. 11, 26
# MENU/DISPLAY Button ................. Z pg. 17, 26
$ •Counter Reset/Memory Button
[COUNTER R/M] .............................. Z pg. 38
•Recording Mode Button [SP/EP] ......... Z pg. 12
% EJECT Switch ....................................... Z pg. 13
^ Recording Start/Stop Button.................. Z pg. 16
& Power Switch ................................ Z pg. 16, 36
* Battery Release Switch
[BATTERY RELEASE] .............................. Z pg. 8
( PUSH Button ....................................... Z pg. 13
Connectors
) DC IN Jack ............................................ Z pg. 9
The connectors q to e are located beneath the
cover.
q Video Output Connector ...................... Z pg. 40
w Audio Output Connector ..................... Z pg. 40
e J Terminal [JLIP (Joint Level Interface Protocol)
Connector]
• It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
• JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
r Tally Lamp ........................................... Z pg. 16
t Power Lamp ........................................ Z pg. 16
Other Parts
y Battery Pack Mount ............................... Z pg. 8
u Viewfinder ........................................... Z pg. 14
i Grip Strap ............................................ Z pg. 14
o Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
p Microphone
For use when recording.
Q Eyepiece .............................................. Z pg. 42
W Shoulder Strap Eyelets .......................... Z pg. 15
E Clock Battery Slot ................................ Z pg. 10
R Tripod Mounting Socket ....................... Z pg. 15
