EN 7
GETTING STARTED
MasterPage: Start_Right
GETTING STARTED
Controls
A Stop Button [8] (墌 pg. 20)
Index Button [INDEX] (墌 pg. 27)
Backlight Compensation Button [BACK
LIGHT] (墌 pg. 40)
B Play/Pause Button [4/9] (墌 pg. 20)
Manual Focus Button [FOCUS] (墌 pg. 38)
C Rewind Button [ 3 ] (墌 pg. 20)
Menu select Button [–] (墌 pg. 15)
Quick Review Button [ ] (墌 pg. 20)
D Fast-Forward Button [ 5 ] (墌 pg. 20)
Menu select Button [+] (墌 pg. 15)
Night Button [NIGHT] (墌 pg. 38)
E Menu Button [MENU] (墌 pg. 31)
Data Battery Button [DATA] (墌 pg. 14)
F VIDEO/MEMORY Switch (墌 pg. 14)
G LED Light Button [LIGHT] (墌 pg. 37)
H Dioptre Adjustment Control (墌 pg. 16)
I Snapshot Button [SNAPSHOT]
(墌 pg. 25, 38)
Live Slow Button [SLOW] (墌 pg. 31, 37)
J Power Zoom Lever [T/W] (墌 pg. 19)
Speaker Volume Control [VOL. +, –]
(墌 pg. 20)
K Battery Release Button [PUSH BATT.]
(墌 pg. 13)
L Recording Start/Stop Button (墌 pg. 18)
M Power Switch [A, M, PLAY, OFF] (墌 pg. 14)
N Lock Button (墌 pg. 14)
O Cassette Open/Eject Switch [OPEN/EJECT]
(墌 pg. 16)
Connectors
The connectors are located beneath the covers.
P USB (Universal Serial Bus) Connector
(墌 pg. 45)
Q S-Video/Audio/Video Input/Output Connector
[S/AV] (墌 pg. 22, 43)
R DC Input Connector [DC] (墌 pg. 13)
S Digital Video Connector [DV IN/OUT] (i.Link*)
(墌 pg. 44, 45)
T Microphone connector [MIC] (墌 pg. 34, 46)
(An optional microphone can be used during
video recording and audio dubbing. To
stabilise the microphone, use of an optional
shoe adapter is recommended.)
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
Indicators
U POWER/CHARGE Lamp (墌 pg. 13, 18)
Other Parts
V Monitor Latch (墌 pg. 18)
W LCD Monitor (墌 pg. 18, 19)
X Viewfinder (墌 pg. 16)
Y Card Cover [MEMORY CARD] (墌 pg. 17)
Z Battery Pack Mount (墌 pg. 13)
a Shoulder Strap Eyelet (墌 pg. 11)
b Speaker (墌 pg. 20)
c Grip Strap (墌 pg. 15)
d Lens
e LED Light (墌 pg. 37)
(When using an optional conversion lens, it
may cover this area and block the light.)
f Remote Sensor (墌 pg. 23)
g Camera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
h Stereo Microphone (墌 pg. 46)
i Stud Hole (墌 pg. 16)
j Tripod Mounting Socket (墌 pg. 16)
k Cassette Holder Cover (墌 pg. 16)
GR-D290_270Asia.book Page 7 Monday, October 25, 2004 10:10 PM
