GETTING STARTED
16 EN
MasterPage: Left
1 Set the Power Switch to “REC” while pressing
down the Lock Button located on the switch.
2 Make sure the LCD monitor is closed and
locked. Pull out the viewfinder fully and adjust it
manually for best viewability.
3 Turn the Dioptre Adjustment Control until the
indications in the viewfinder are clearly focused.
CAUTION:
When retracting the viewfinder, take care not to
pinch your fingers.
1 Set the Power Switch
to “REC” or “PLAY” while
pressing down the Lock
Button located on the
switch.
2 Open the LCD monitor
fully. (墌 pg. 18)
● To adjust the brightness of
the viewfinder, pull out the
viewfinder fully and set
“PRIORITY” to “FINDER”
(墌 pg. 23,25).
3 Press MENU. The
Menu Screen appears.
If you are in Playback mode, please proceed to
step 5.
4 Press or to select “DISPLAY”, and
press SET or . The DISPLAY Menu appears.
5 Press or to select “BRIGHT”, and press
SET or . The Menu Screen closes and the
brightness control MENU appears.
6 Press or until the appropriate
brightness is reached and press SET or .
7 Press MENU. The Menu screen closes.
To attach the camcorder
to a tripod, align the
direction stud and screw
to the mounting socket
and stud hole on the
camcorder. Then tighten
the screw clockwise.
● Some tripods are not
equipped with studs.
Viewfinder Adjustment
Dioptre Adjustment Control
Example:
Brightness Adjustment Of The
Display
Tripod Mounting
BRIGHT
MENU
G R -D 3 4 0 P A L .b o o k P a g e 1 6 Thursday , Octo ber 27 , 2005 3:19 PM
