JVC GR-DVL100U Technical Guide

2-29
2.5.8 Deck DSP IC function
1. Deck DSP (IC3001: JCY0106-2) pin functions (1/6)
Pin No. Label In/Out Description
69 VDD - Power supply
1 GND - Ground
134 PWMAUDO Out Audio PLL control signal, (To DVANA: IC3301)
70 VDDS
2VDD
71 VCOAUDI In PB audio b PLL input, (From DVANA: IC3301)
3 VCOAUDO Out PB audio b PLL adjustment voltage output
135 GND - Ground
189 VDD - Power supply
226 OSC32I - L: Fixed (Not used)
72 - - Not used
4 OSC32O - Open (Not used)
136 OSC44I - L: Fixed (Not used)
73 OSC44O - Open (Not used)
190 OSC48I In 24.5MHz clock input
5 OSC48O Out 24.5MHz clock output
227 GND - Ground
137 AUDIOTESTI - L: Fixed
74 AUDIOTESTIO - H: Fixed
6 VDDS - Power supply
191 DILRCK
138 DIBCK
75 DIMCK
7DIDAT
8 AILRCK Out Serial I/O interface channel clock for ADC, (To ADC: IC2101)
76 AIBCK Out Audio serial data clock, (To ADC: IC2101)
139 AIMCK Out Audio master clock, (To ADC: IC2101)
192 PHYCLK Out IEEE 1394 crystal oscillator output (27MHz), (To 1394 PHY: IC3101)
228 GND - Ground
9 AIDAT [0]
77 AIDAT [1]
140 DOLRCK
193 DOBCK
229 DOMCK
10 DODAT
78 VDD - Power supply
141 AOLRCK
230 AOBCK
194 AOMCK
11 AODAT [0] Out Audio serial data output, (To ADC: IC2101)
79 AODAT [1] - Open (Not used)
142 VDDS - Power supply
231 GND - Ground
Open (Not used)-
L: Fixed (Not used)-
Audio serial data input, (From ADC: IC2101)In
- Power supply
Open (Not used)-
Table 2-5-4 Deck DSP (IC3001: JCY0106-2) pin functions (1/6)
