USING THE REMOTE CONTROL UNIT
The Full-Function Remote Control Unit can operate
this camcorder from a distance as well as the basic
operations (Playback, Stop, Pause, Fast-Forward and
Rewind) of your VCR. It also makes additional
playback functions possible.
Installing The Batteries
The remote control uses two “AAA (R03)” size
batteries. See “General Battery Precautions”
(墌 pg. 60).
1Remove the battery compartment cover while
pushing up the tab as illustrated.
2 Insert two ”AAA (R03)” size batteries in the
correct direction.
3 Re-attach the battery compartment cover.
When using the remote control, be sure to point it at the
remote sensor. The transmitted beam’s approximate
effective distance for indoor use is 5m.
The transmitted beam may not be effective or may cause
incorrect operation outdoors or when the remote sensor is
directly exposed to sunlight or powerful lighting.
Tab
Remote sensor
