Controls
1 Monitor Open Button
[PUSH OPEN] ..................................... 墌 pg. 14
2 Diopter Adjustment Control ................. 墌 pg. 10
3 Battery Release Button
[BATTERY RELEASE] .............................. 墌 pg. 9
4 •MENU Wheel [+, –, PUSH] ............... 墌 pg. 22
•LCD Monitor BRIGHT
(Brightness) Control [+, –] .................. 墌 pg. 14
5 Snapshot Button
[SNAPSHOT] ................................. 墌 pg. 16, 17
6 •Power Zoom Lever [T/W] .................. 墌 pg. 18
•Speaker Volume Control [VOL.] ........ 墌 pg. 31
7 Snapshot Mode Button
[MODE] .............................................. 墌 pg. 16
8 OPEN/EJECT Switch ............................. 墌 pg. 12
9 Stop Button [5] ................................... 墌 pg. 31
0 •Rewind Button [
2
] ......................... 墌 pg. 31
•BACKLIGHT Button .......................... 墌 pg. 29
! Play/Pause Button [
4
/6] ...................... 墌 pg. 31
@ •Fast-Forward Button [
3
] ................. 墌 pg. 31
•FOCUS Button .................................. 墌 pg. 21
# Power Switch
[ , , , OFF] ........................... 墌 pg. 15
$ Recording Start/Stop Button.................. 墌 pg. 14
% Lock Button ......................................... 墌 pg. 14
^ Video Light Switch
[LIGHT OFF/AUTO/ON] ...................... 墌 pg. 20
Connectors
To connect cables to the following connectors
&
and
*
,
open the LCD monitor.
& PC (DIGITAL PHOTO) Connector ........ 墌 pg. 36
* J Terminal/Edit Connector [JLIP (Joint Level
Interface Protocol)/EDIT] ...................... 墌 pg. 45
• Connect the editing cable when performing
Random Assemble Editing.
• Connect to a JLIP-compatible camcorder or VCR
to control it from the computer using the
provided Software.
( DC Input Connector .............................. 墌 pg. 9
The connectors
)
to
w
are located beneath a cover.
) Audio/Video Output Connector
[AV] ........................................ 墌 pg. 34, 38, 45
q Digital Video Connector [DV IN/OUT]
(i.link*) .................................... 墌 pg. 36, 37, 39
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.Link
standard.
w S-Video Output Connector [S] ... 墌 pg. 34, 38, 45
Indicators
e Tally Lamp ........................................... 墌 pg. 14
r Side LED Indicator
(GR-DVL500 only) ............................... 墌 pg. 24
t Power Lamp ........................................ 墌 pg. 14
Other Parts
y • Remote Sensor .................................. 墌 pg. 40
• Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
u Viewfinder ........................................... 墌 pg. 10
i Video Light .......................................... 墌 pg. 20
o Stereo Microphone .............................. 墌 pg. 50
p Shoulder Strap Eyelets .......................... 墌 pg. 10
Q Grip Strap ............................................ 墌 pg. 10
W Battery Pack Mount ............................... 墌 pg. 9
E LCD Monitor ................................. 墌 pg. 14, 15
R Speaker ............................................... 墌 pg. 31
T Stud Hole ............................................ 墌 pg. 10
Y Tripod Mounting Socket ....................... 墌 pg. 10
