EN79
Docking Station
General
Dimensions : 115 mm (W) x 31 mm (H) x 55 mm (D)
Weight : Approx. 90 g
Connectors
S-Video : Y: 1 Vp-p, 75 Ω, analogue output
C: 0.29 Vp-p, 75 Ω, analogue output
Video : 1 Vp-p, 75 Ω, analogue output
Audio : –8 dBs, 1 kΩ, analogue output
JLIP : ø3.5 mm, 4-pole, mini-head jack (compatible with RC-5325 plug)
Editing : ø3.5 mm diameter, 2-pole
PC : ø2.5 mm, 3-pole
External microphone input : –68 dBs, high impedance unbalanced with ø3.5 mm (stereo)
E & O.E. Design and specifications subject to change without notice.
