SPECIFICATION
Design and specifications are subject to change without notice.
Amplifier section
(CA-HXD77)
Output Power SUBWOOFERS 125 W per channel, min. RMS, driven into 3 Ω at 100 Hz with no more
than 10% total harmonic distortion. (IEC 268-3) (at 230 V , 50 Hz)
MAIN SPEAKERS 90 W per channel, min. RMS, driven into 6 Ω at 1 kHz with no more
than 10% total harmonic distortion. (IEC 268-3) (at 230 V , 50 Hz)
Audio input sensitivity/
impedance
AUX 400 mV/47 kΩ
USB USB Version 1.1
Video input sensitivity/
impedance
GAME/AUX
(composite video)
1 V(p-p)/75 Ω
Digital output DIGITAL OUTPUT (OPTICAL) -21 dBm to -15 dBm (660 nm ±30 nm)
VIDEO OUT Color system NTSC or PAL
VIDEO (composite) 1 V(p-p)/75 Ω
S-VIDEO Y (luminance) : 1 V(p-p)/75 Ω
C (chrominance, burst) : NTSC : 0.286 V(p-p)/75 Ω
C (chrominance, burst) : PAL : 0.3 V(p-p)/75 Ω
Speaker Terminals 6 Ω - 16 Ω (main speakers)
3 Ω - 6 Ω (subwoofers)
Tuner section FM tuning range 87.5 MHz - 108.0 MHz
AM tuning range 530 kHz - 1 710 kHz (at 10 kHz intervals)
531 kHz - 1 710 kHz (at 9 kHz intervals)
Disc player section Playable disc DVD Video CD/VCD/SVCD
CD-R/CD-RW (recorded in Audio CD/Video CD/Super Video CD/MP3/
WMA/JPEG format)
DVD-R/DVD-RW (recorded in DVD-Video or DVD-VR format)
+R/+RW (recorded in DVD-Video or DVD-VR format)
Dynamic range 90 dB
Horizontal resolution 500 lines
Wow and flutter Immeasurable
General Power requirement AC 110 V - AC 240 V , 50/60 Hz
Power consumption 90 W/ 150 VA (at operation)
8 W (on standby: with power saving off-Normal mode)
1 W (on standby: with power saving on-Eco mode)
Dimensions (approx.) (W/H/D) 175 mm × 373 mm × 411 mm (6 15/16 in. × 14 11/16 in. × 16 3/16 in.)
Mass (approx.) 5.8 kg (12.8 lbs)
Speaker section
(SP-HXD77)
Type 4-Way Front Twin Woofer (Magnetically Shielded Type)
Speakers Subwoofer 16 cm (6 5/16 in.) cone × 1
Woofer 16 cm (6 5/16 in.) cone × 1
Mid range 7 cm (2 13/16 in.) cone × 1
Tweeter 2 cm (13/16 in.) piezo × 1
Power handling capacity Subwoofer 180 W
Main speaker 90 W
Impedance Subwoofer 3 Ω
Main speaker 6 Ω
Frequency range Subwoofer 30 Hz - 1 000 Hz
Main speaker 50 Hz - 20 000 Hz
Sound pressure level Subwoofer 73 dB/W·m
Main speaker 82 dB/W·m
Dimensions (approx.) (W/H/D) 296 mm × 453 mm × 343 mm (11 11/16 in. × 17 7/8 in. × 13 9/16 in.)
Mass (approx.) 7.5 kg (16.5 lbs) each
