HX-Z1R
3-12
Item
Parts number Parts name Ar
ea
Remarks
A
C 250 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C 251 QETN1CM-477Z E CAPACITOR 470MF 20% 16V
C 252 QCZ9105-472 C CAPACITOR
A
4700PF
C 253 QFLM1HJ-472Z M CAPACITOR 4700PF 5% 50V
C 255 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 308 QEKC1HM-106Z E CAPACITOR 10MF 20% 50V
C 311 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 312 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 362 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C 703 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 705 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 706 QCBB1HK-221Y C CAPACITOR 220PF 10% 50V
C 707 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 708 QETN1JM-476Z E CAPACITOR 47MF 20% 63V
C 709 QCSB1HK-4R7Y C CAPACITOR 4.7PF 10% 50V
C 710 QCSB1HK-4R7Y C CAPACITOR 4.7PF 10% 50V
C 711 QFZ0212-104Z MM CAPACITOR .10MF
C 712 QFZ0212-104Z MM CAPACITOR .10MF
C 713 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V
C 714 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V
C 715 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V
C 716 QFLM1HJ-473Z M CAPACITOR .047MF 5% 50V
C 721 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C 722 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C 723 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C 726 QETN1EM-106Z E CAPACITOR 10MF 20% 25V
C 729 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C 730 FQCF31HZ-223Z D CAPACITOR
C 731 FQCF31HZ-223Z D CAPACITOR
C 739 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
CN212 QGD2504C1-03Z SOCKET
CN213 QGD2504C1-04Z SOCKET
CN214 QGA3901C1-05 CONNECTOR
CN215 QGB2510K2-15 CONNECTOR
CN231 QGD2504C1-03Z SOCKET
CN232 QGD2504C1-03Z SOCKET
CN250 QGA7901F2-02 CONNECTOR
CN301 QGB2510K2-11 CONNECTOR
D 233 2A02-M DIODE
A
D 234 2A02-M DIODE
A
D 235 2A02-M DIODE
A
D 236 2A02-M DIODE
A
D 252 1N4003S-T5 SI DIODE
A
D 254 1SS119-041-T2 SI DIODE
A
D 256 DZ6.2BSC-T2 ZENER DIODE
D 313 DZ10BSC-T2 ZENER DIODE
D 315 DZ11BSC-T2 ZENER DIODE
D 360 1SS119-041-T2 SI DIODE
D 362 DZ8.2BSC-T2 ZENER DIODE
D 703 DZ15BSC-T2 ZENER DIODE
D 704 DZ15BSC-T2 ZENER DIODE
D 719 1SS119-041-T2 SI DIODE
D 720 1SS119-041-T2 SI DIODE
D 723 DZ36BSA-T2 ZENER DIODE
D 724 DZ36BSA-T2 ZENER DIODE
D 726 1SS119-041-T2 SI DIODE
D 728 1SS119-041-T2 SI DIODE
FT111 QNG0003-001Z FUSE CLIP
A
FT112 QNG0003-001Z FUSE CLIP
A
FT511 QNG0003-001Z FUSE CLIP
A
FT512 QNG0003-001Z FUSE CLIP
A
FT521 QNG0003-001Z FUSE CLIP
A
FT522 QNG0003-001Z FUSE CLIP
A
FT532 QNG0003-001Z FUSE CLIP
A
IC303 KIA7808API IC
A
IC305 KIA7809API IC
A
IC360 KIA7805API IC
A
IC701 STK412-010 IC(HYBRID)
A
L 701 QQLZ035-R39 INDUCTOR
L 702 QQLZ035-R39 INDUCTOR
Q
250 2SC2785/FE/-T TRANSISTOR
Q
251 KTC1027/OY/-T TRANSISTOR
Q
701 KTA1268/GL/-T TRANSISTOR
Q
702 KTA1268/GL/-T TRANSISTOR
Q
710 KTA1023/OY/-T TRANSISTOR
Q
711 KTC3200/GL/-T TRANSISTOR
Q
712 KTA1268/GL/-T TRANSISTOR
Q
713 KTC1027/OY/-T TRANSISTOR
Q
726 KTC3200/GL/-T TRANSISTOR
Q
727 KTA1268/GL/-T TRANSISTOR
Q
728 2SC2785/FE/-T TRANSISTOR
R 250 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 253 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 362 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 701 QRJ146J-470X UNF C RESISTOR
A
47 5% 1/4W
R 702 QRJ146J-470X UNF C RESISTOR
A
47 5% 1/4W
R 703 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 704 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 705 FQRJ143J-821X UNF C RESISTOR
A
R 706 FQRJ143J-821X UNF C RESISTOR
A
R 707 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 708 QRE141J-563Y C RESISTOR 56K 5% 1/4W
R 713 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 714 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 715 FQRJ143J-100X UNF C RESISTOR
A
R 716 FQRJ143J-100X UNF C RESISTOR
A
R 717 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 718 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 719 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 720 QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
R 721 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 722 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 723 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 724 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 727 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 728 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 729 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 730 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 739 QRE141J-823Y C RESISTOR 82K 5% 1/4W
R 740 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 741 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 742 QRE141J-682Y C RESISTOR 6.8K 5% 1/4W
R 753 QRZ0197-R22 C RESISTOR
A
1W
R 754 QRZ0197-R22 C RESISTOR
A
1W
R 761 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 762 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 766 QRE141J-333Y C RESISTOR 33K 5% 1/4W
R 768 QRE141J-104Y C RESISTOR 100K 5% 1/4W
R 769 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 774 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 775 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 777 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 778 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 786 QRE141J-103Y C RESISTOR 10K 5% 1/4W
R 787 QRE141J-103Y C RESISTOR 10K 5% 1/4W
RY 3 QSK0140-001 RELAY
A
T 002 QQT0253-002 POWER TRANS
A
Electrical parts list (Power amplifier board)
Block No. 01
Item
Parts number Parts name Ar
ea
Remarks
A
FT531 QNG0003-001Z FUSE CLIP
A
www.freeservicemanuals.info
3/29/2018
Digitized in Heiloo Netherlands
